TORQUE MEASUREMENT

FLANGE MOUNTED TRANSDUCERS (FMT)
Calibration details

FMT FMT FMT
Model
(2 N·m - 25 N·m) (60 N·m - 400 N·m) (1,500 N·m)
50671.xxx 50844.xxx
50672.xxx
Part 50673.xxx 50674.xxx 50676.xxx
Number 50677.xxx 50680.xxx 50682.xxx
50675.xxx
50678.xxx 50681.xxx
50679.xxx
ØA 5.5 8.5 12
ØB 64 90 150
Dimensions (mm) D C 83 (1/4"), 86 (3/8") 92 (1/4"), 95 (3/8"), 101 (1/2") 128 (1/2"),
65
63
84
138 (3/4"),

E 132 192 (60 N·m, 150 N·m & 100 lbf·ft) 138 (1")
N/A
N/A (400 N·m & 250 lbf·ft)
0.8 (2 N·m & 20 lbf·in) 3.3 (60 N·m, 150 N·m & 100 lbf·ft)
Weight 0.8 (10 N·m & 100 lbf·in) 1.5 (400 N·m) 7�0
(kg)
0.9 (25 N·m & 250 lbf·in) 2.7 (250 lbf·ft)

FMT 400 N·m
shown with case
4 FMT (Ancillary Section)
50539 2 N�m Joint Simulator (also fits TST)
50540 10 N�m Joint Simulator (also fits TST)
50541 25 N�m Joint Simulator (also fits TST)
50845 60 N·m Joint Simulator
50692 150 N�m Joint Simulator
50819 400 N�m Joint Simulator

52236 1 ∕ 4" Hexagon - ∕ 4" Square Drive Adaptor
1
52237 1 ∕ 4" Hexagon - ∕ 8" Square Drive Adaptor
3
52251 3 ∕ 8" Female Square - 22 mm Bi-Square Adaptor
52246 1 ∕ 2" Female Square - 22 mm Bi-Square Adaptor FMT Mounting Brackets
52245 3 ∕ 4" Female Square - 22 mm Bi-Square Adaptor 4 FMT Mounting Brackets
52254 1 ∕ 2" Female Square - 35 mm Bi-Square Adaptor 62221.BLK9005 FMT Mounting Bracket 2 - 400 N�m
52241 3 ∕ 4" Female Square - 35 mm Bi-Square Adaptor 62220.BLK9005 FMT Mounting Bracket 150 - 1,500 N�m
52242 1" Female Square - 35 mm Bi-Square Adaptor
