TORQUE MEASUREMENT

ANNULAR TRANSDUCERS
Calibration details

These Annular Transducers are designed to fit directly to Norbar torque multipliers and will
accurately measure the torque output from the gearbox, via a display instrument (instrument
supplied separately, see pages 93 - 94 & 96).
• Up to 6,000 N�m classified to BS7882:2017, typically better than Class 1 for the primary classification
range (±0.5% of reading from 20% to 100% of full scale)
• Robust heat treated alloy steel torsion tube design
• Designed to ignore non-torsional forces
• Smart transducers have a built in memory circuit which contains essential information about the
transducer. This information can be read by Norbar’s TST, TTT, TTL-HE & T-Box™ 2 instruments
meaning that when the transducer is connected, it is immediately recognised and ready for use
• Smart transducers can also be used with many other instruments, however, these will operate as normal
ratio calibrated (mV/V) transducers - the Smart data will not be read
4 ANNULAR TRANSDUCERS FOR STANDARD SERIES 4 ANNULAR TRANSDUCERS FOR
GEARBOX STANDARD SERIES GEARBOX
Suitable for PT1, PT1A and PT2 Suitable for HT9 and PT9
50638.xxx 100 - 1,000 N�m ∕ 4" sq� dr� 50644.xxx 1,000 - 10,000 N·m 1 ∕ 2" sq� dr�
3
1
50648.xxx 100 - 1,000 lbf�ft ∕ 4" sq� dr� 50653.xxx 700 - 7,000 lbf�ft 1 ∕ 2” sq. dr.
1
3
Suitable for heavy duty HT2, PT1, PT1A and PT2 Suitable for HT11 and PT11
50639.xxx 150 - 1,500 N�m 1" sq. dr. 50645.xxx 2,000 - 20,000 N�m 2 ∕ 2" sq� dr�
1
50649.xxx 150 - 1,500 lbf�ft 1" sq. dr. 50654.xxx 1,500 - 15,000 lbf�ft 2 ∕ 2" sq� dr�
1
TD2�CCW Alternative calibration direction for transducers up to Suitable for HT12 and PT12
1,500 N�m / 1,000 lbf�ft when ordered with new unit 50764.xxx 3,500 - 35,000 N�m 2 ∕ 2" sq� dr�
1
50765.xxx 2,500 - 25,000 lbf�ft 2 ∕ 2" sq� dr�
1
Suitable for HT5 and PT5
50640.xxx 250 - 2,500 N�m 1" sq. dr. Suitable for HT13 and PT13
1
50650.xxx 250 - 2,500 lbf�ft 1" sq. dr. 50646.xxx 5,000 - 50,000 N�m 2 ∕ 2" sq� dr�
50641.xxx 350 - 3,500 N�m 1" sq. dr.
Suitable for PT14
50647.xxx 10,000 - 100,000 N�m 3 ∕ 2" sq� dr�
1
Suitable for HT6 and PT6
50700.xxx 350 - 3,500 N�m 1 ∕ 2" sq�dr� TD4�CCW Alternative calibration direction for transducers from
1
7,001 - 100,000 N�m / 5,001 - 75,000 lbf�ft when ordered
Suitable for HT7 and PT7 with new unit
50643.xxx 500 - 5,000 N�m 1 ∕ 2" sq� dr�
1
50652.xxx 500 - 5,000 lbf�ft 1 ∕ 2" sq� dr� Suitable for PT18.MTS
1
TD5�CCW@ Alternative calibration direction for transducers from - 30,000 - 300,000 N�m
1,501 - 7,000 N�m / 1,001 - 5,000 lbf�ft when ordered with new Standard calibration is performed loading counter-clockwise only.
unit
@ UKAS accredited calibration up to 6,000 N�m. A non-accredited value at
7,000 N�m is extrapolated and provided for reference only.

PT 18 fitted with 300,000 N·m
Annular Transducer and square drive
Model Annular Transducers for use with Standard Series Multipliers
50638.xxx 50640.xxx
50648.xxx 50650.xxx 50643.xxx
Part Number
50639.xxx 50641.xxx 50652.xxx
50649.xxx 50700.xxx
Dimensions ØA 108 119 144
(mm) B 60 65 71
Weight (kg) 1�4 2�6 3�6
