TORQUE MEASUREMENT

ANNULAR TRANSDUCERS
Calibration details

4 TORQUE & ANGLE ANNULAR TRANSDUCERS - 4 TORQUE & ANGLE ANNULAR TRANSDUCERS -
FIXED CONNECTOR 180° SWIVEL CONNECTOR
Suitable for heavy duty PT1, PT1A and PT2 Suitable for HT7 and PT7
50820�LOGA* 100 - 1,000 N�m ∕ 4" sq� dr� 50834�LOGA 500 - 5,000 N�m 1 ∕ 2" sq� dr�
3
1
50821�LOGA* + 150 - 1,500 N�m 1" sq. dr.
* Can only be used with remote/plain sleeve motors i.e. not a standard PT handle, due Suitable for HT9 and PT9
to cable interference. 50824�LOGA 1,000 - 10,000 N�m 1 ∕ 2" sq� dr�
1
Only fits to PT with HD final stage carrier having 1" female sq. dr.
+
Suitable for HT11 and PT11
Suitable for HT5 and PT5 50825�LOGA 2,000 - 20,000 N�m 2 ∕ 2" sq� dr�
1
50822�LOGA 350 - 3,500 N�m 1" sq. dr.
Suitable for HT12 and PT12
50826�LOGA 3,500 - 35,000 N�m 2 ∕ 2" sq� dr�
1
Suitable for HT13 and PT13
50827�LOGA 5,000 - 50,000 N�m 2 ∕ 2" sq� dr�
1
Suitable for HT14 and PT14
50828�LOGA 10,000 - 100,000 N�m 3 ∕ 2" sq� dr�
1
PT13 & PT14 require special front cover plate with added dowel clearance holes
Suitable for HT15 and PT15
50832�LOGA 15,000 - 150,000 N�m 4 ∕ 2" sq� dr�
1
Suitable for HT16 and PT16
Torque & Angle
Model Annular Transducers 50829�LOGA 20,000 - 200,000 N�m 5" sq. dr.
with Fixed Connector
Suitable for HT17 and PT17
50820.LOGA
Part Number 50821.LOGA 50830�LOGA 25,000 - 250,000 N�m 6" sq. dr.
50822.LOGA
Suitable for HT18 and PT18
A 89
Dimensions 50831�LOGA 30,000 - 300,000 N�m 6" sq. dr.
(mm) ØB 119
C 65
Weight (kg) 1�4
Fixed Connector

180° Swivel Connector

Torque & Angle Annular Transducers with Swivel Connector
Model
5,000 N·m 10,000 N·m 20,000 N·m 35,000 N·m 50,000 N·m 100,000 N·m 150,000 N·m 200,000 N·m 250,000 N·m 300,000 N·m
Part Number 50834.LOGA 50824.LOGA 50825.LOGA 50826.LOGA 50827.LOGA 50828.LOGA 50832.LOGA 50829.LOGA 50830.LOGA 50831.LOGA
A 108 120 140 151 186 186 * * * 289
Dimensions ØB 144 178 212 248 315 315 * * * 520
(mm)
C 144 184 212 240 315 315 * * * 520
Weight (kg) 7�0 10�0 15.0 29�3 43.5 46�6 * * * 149.5
* Available on request
