TORQUE MEASUREMENT

TORQUE WRENCH CALIBRATOR - AUTO
Calibration details

For a complete torque wrench calibration system, just add the • Calibration job management; book calibrations, track progress of
transducer range appropriate for the wrenches you wish to previous bookings and resume them
calibrate and accessories from page 110. • Automated management of calibration and conformance workflows
for non-indicating tools
• Enables torque wrench calibration or testing in accordance with ISO • Intelligent rate control system ensures fast cycling of tools while
6789:2017 Part 1 and 2 maintaining compliance with 2017 standards
• Counterbalance Reaction system is designed to support the weight • Environmental monitoring (humidity/temperature) to assist
of the wrench so that the weight does not become a parasitic force compliance with calibration standards
within the calibration system. The floating nature of the support • Automated management of uncertainty data for ISO 6789-2:2017
means that the wrench is able to find its own natural level rather calibrations, guiding the user through the process using dynamically
than being constrained as in many other loading devices� Any such generated instructions based on the current tool’s ISO classification
constraint will be a parasitic force within the system (Patents apply) and workflow
• Lightweight alloy construction ensures the TWC is easily • Inbuilt data analysis and certification generation seamlessly move
transported, making it well suited for mobile laboratory applications from calibration/conformance procedure to certificate generation,
• Works with Flange Mounted Transducers and Static Transducers no third-party software required
• During calibration, the TWC maintains a fixed position on the handle • A substantial amount of inbuilt storage allowing for several years'
of the torque wrench worth of calibration data through normal use
• Rotating transducer design ensures that the load is applied 90° to • The TWC control Box is supported by a UKAS accredited certificate
the torque wrench handle. The benefit of this precise alignment is of calibration, we remain one of the few manufacturers in the world
that forces are applied squarely to the load point of the handle that issue a UKAS accredited calibration certificate both for the
• Supplied with a powerful yet simple touchscreen User Interface (UI) instrument and for the torque transducer. In doing so, customers
(keyboard and mouse also supported if desired) can swap combinations of instrument and transducer while
• Flexible tool template system; minimises number of templates retaining complete traceability
required to cover a wide range of tools, aiding efficient use • When testing for conformity or calibrating to ISO6789:2017 any
• Programmable calibration workflow for each template, can be pre- transducer must not be used below 5% of its capacity when used
set to ISO compliant flow for the given tool for a faster set-up or can with TWC. This statement does not apply to a TWC when used in a
also support bespoke workflows accredited laboratory
5 TORQUE WRENCH CALIBRATOR (TWC)
60312 Torque Wrench Calibrator 400 N·m Auto
60313 Torque Wrench Calibrator 1,500 N·m Auto

Torque Wrench Calibrator (TWC) Auto shown with a Professional Model 200
and a Static Transducer with support kit (not included)
