TORQUE MEASUREMENT

TEST RIGS AND FIXTURES

4 REACTION PLATES FOR USE WITH 50803 & 50804

81024 Suitable for ET/EBT/PTS/PTM 119, PT 4500 and PT 5500

81025 Suitable for ET/EBT/PTS/PTM 92

Power Tool Test Rig
with Reaction Plates (50800)

81026 Suitable for ET/EBT/PTS/PTM 72

81027 Suitable for PTS/PTM 52

81028 Suitable for PT 2700

Universal Hydraulic Tool Test Rig
with Reaction Plates (50801)

81029 Suitable for PT 1, PT 1A and PT 2

4 SPARES FOR 50800, 50801, 50803 & 50804 81030
50800�29 2" AF Socket 1 ∕ 2" sq� dr� Suitable for PT 5 and PT 6
1
50800�28 2" AF Socket 1" sq� dr�
50800�27 2" AF Socket ∕ 4" sq� dr�
3

81031 Suitable for PT 7

81041 Nut and bolt set for 7,000 N·m Power Tool Test Rigs
50548�4 Washer Stack Kit 100 - 7,000 N�m
(Also for use with RD5000)
81032 Blank Reaction Plate for Universal Test Rigs
See page 117 & page 119 for accessories for use with Hydraulic Tool
Calibration Fixture. NOTE: Reaction plate dimensions can be found by searching their part
number on the Norbar website�
