MarShaft Software EasyShaft

DESCRIPTION

• MarWin EasyShaft software is the measuring, control and evaluation
system for the MarShaft SCOPE plus. It offers precision measurement of
diameters, lengths, contour features and form and position tolerances
in accordance with standards, along with many new evaluation and
documentation options, all with a well-laid-out, intuitive user interface.
• The software runs entirely under the familiar Windows operating
®
®
system. The user interface is compatible with other Windows applica-
®
tions, reducing the familiarization time substantially. All Windows -com-
patible printers can be used for record output.
Performance features at a glance:
®
• The familiar Windows user interface makes for a short learning curve
• The user interface is used as standard across all Mahr products (e.g.
EasyForm or Contour 1)
• Clear, windows-based layout
• User-friendly, 100% touchscreen functionality
• Predefined macros for easy programming (e.g. diameter measurement
at a mouse click)
• Many functions can be selected directly via obvious icons
• Touchscreen-controllable machine axes
• The live image from the matrix camera is permanently displayed during
measurement, i.e. direct visual assessment of the workpiece condition
(e.g. soiling) even during measurement
• For individual and serial measurements: the ideal operating strategy for
every task
• User-friendly, state-of-the-art measuring program management
• Time-optimized measuring program sequence (shortest measuring
times)
• Meaningful measuring records – in black-and-white or color – output to
®
all Windows printers
• Future-proof investment, runs under Windows 10
• Optional data export to statistics programs extends the range of func-
tions of the EasyShaft software
Options:
EasyShaft program window
• The EasyShaft software gives you full control over the MarShaft SCOPE.
The touchscreen gives you direct access to positioning, programming,
measurement and documentation. The excellent, simple user interface
helps you keep track of everything you need to know.
• Many functions, such as loading measuring results or adding feature
measurements, can be selected simply by clicking an icon.

EasyShaft commands
• The clearly laid-out command bar contains all the commands required
for measuring and evaluating features.
• Macros (composed sequences of evaluation actions, e.g. diameter,
radius, distance or angle)
• Features which can be calculated (e.g. direct distance, distance in X and
Z, angle, angle sector, radius, roundness, straightness, radial run-out,
axial run-out, cylindricity, symmetry)
• Substitute elements which can be calculated (e.g. point, line, circle,
point on straight line, intersection point, symmetry straight line, parallel
straight line, extreme point, C-reference)
• Display palette (touchscreen control of machine axes)
• Used to show or hide the display palette
• Used to select the zoom range
• Joystick for the C-axis
• Joystick for the X- and Z-axis
• Zoom in incrementally
• Zoom in or out continuously
• Zoom out incrementally
