MarShaft

Engineered Solutions

DESCRIPTION

Shaft measuring system for the intelligent and cross-linked produc-
tion of the future.
The advancing digitalization and automation also demands from measure-
ment technology to adapt to new requirements – in terms ofspeed and
reliability, for example.
That is why Mahr has been developing measuring systems for the intelli-
gent factory: measuring instruments that can be loaded by robots and that
measure automatically.
For the MarShaft Scope product family, Engineered Solutions offers con-
cepts that can deliver fully automated quality assurance, without operator
intervention, round the clock. In this way you can increase production
efficiency, optimize process costs and boost product safety. The cameras
used at Mahr optically detect features such as diameters, lengths, radii,
form or position features contactlessly and with maximum precision, in
just a few seconds.

Intelligent measuring machine with robot loading
As a Mahr customer you benefit from a comprehensive approach to inte-
grating the measuring process into the existing production environment,
through fully automatic robot loading and the proven performance fea-
tures of the MarShaft Scope 600 plus 3D or MarShaft Scope 750.
If you need an additional measuring machine to solve the measuring tasks,
the robot can transfer the workpiece to different stations for further
measurements.
Using the Fieldbus interface in the MarWin platform software, measuring
stations from all product groups can easily be integrated into the produc-
tion process to design the measuring room of the future.

Fixtures for each measuring task
Mahr has a wealth of knowledge regarding the design of highly accurate
fixtures for shaft measurement. For the measuring room of the future,
fixtures will also need to be designed so that they clamp the workpiece in
a secure and reproducible manner, even when loaded by a robots.
Even when no fully automatic and robot-loaded measuring machine is
used, Engineered Solutions with its broad portfolio of various clamping
device concepts can deliver a solution for the measuring task: from differ-
ent tip shapes (hollow tips, centering tips), angles or diameters through to
collet chucks or patented mandrels.
Together with you, we can find the right fixture for your measuring task.

For more information, please visit our website: www.mahr.com
