MarShaft SCOPE plus

Universal, fully automatic optical Shaft Measuring System MarShaft SCOPE 250 plus

DESCRIPTION

• The role of dimensional metrolo-
gy is expanding at a dramatic
rate, in parallel with innovations
in manufacturing processes.
Given the ever more stringent
accuracy requirements and
falling cycle times in production
(turning, milling, grinding, etc.),
rapid measurement directly at
the manufacturing machine is
absolutely essential. Measure-
ment at the point of origin of
the product, with rapid feedback
to the manufacturing process
to avoid waste. Mahr’s flexible
MarShaft SCOPE 250 plus shaft
measuring machine offers the
right measuring solution for the
fast, precise and fully automatic
measurement of rotationally TECHNICAL DATA
symmetrical workpieces in
production. MarShaft SCOPE 250 plus
Measuring range length (Z) (mm) 250
• The MarShaft SCOPE 250 plus Measuring range diameter (X) (mm) 40
has a high precision round- Length/diameter resolution (mm) 0.01...0.0001
ness measuring axis (C) and a
vertical measuring axis (Z) with a Angle resolution (°) 0.01...0.0001
measuring range of 250 mm. At Length error limit (Z) (µm) ≤ (3.0+l/125) L in mm
its heart is the state-of-the-art, Diameter error limit (X) (µm) ≤ (1.5+l/40) L in mm
high-resolution CMOS matrix Lens Telecentric precision optics
camera (live image) with an High-resolution CMOS camera
image field of 1088 x 2048 mm.
The extremely high image acqui-
sition rate of over 120 images APPLICATIONS
per second keeps measuring
times to a minimum. Zoom func- The main measurable features
tions allow the smallest details
to be measured, which with • Length
conventional measuring methods • Diameter
are difficult if not impossible to • Form and position tolerances
test. • Offsets
• Recess width
Performance features at a • Bevel width
glance: • Intersection points
• New, high-resolution CMOS • Position of intersection points
matrix camera with a 40 mm live • Angles of rotation
image field allows fast scanning • Radii
with over 120 images per second • Position of radii
• High accuracy for diameter and • Taper lengths
length measurement • Angles
• Measuring speeds of up to 200 • Pitches
mm/s result in extremely fast • Widths across flats
measuring times • Outer threads
• By using Mahr’s MarWin soft-
ware platform, you can benefit
from our decades of experience
in length, form, position and
contour measurement
• Excellent entry level price into
the small optical shaft measuring
machine segment

For more information, please visit our website: www.mahr.com
