Engineered Solutions

Customized Measuring Technology

DESCRIPTION

Mahr – a full-service Provider for your Measuring System
As your partner from the initial inquiry to commissioning at your site,
Engineered Solutions offers a complete solution:

• Project management
• Design and development
• Commissioning
• Instruction and training at the customer’s site
• Support from the start of the project right up to the turnkey handover
• After sales service

Experience and international Presence
Many years of experience with a large range of different system solutions
makes Engineered Solutions your competent partner for individual
measurement tasks worldwide. Together with the companies belonging
to the Mahr Group, Mahr MWF GmbH (Großostheim / Germany), SMPR
(Grand Couronne / France) and Mahr Inc. (Providence / USA), the team
from Engineered Solutions in Goettingen (Germany) offers concentrated
expertise. Mahr is also represented in Asia when it comes to customer-
specific measuring stations: In Suzhou, China, Mahr has its own office
from which customers are comprehensively supported.

The Right Solution for your Application
With Engineered Solutions, Mahr combines the know-how of various
product groups and designs customized measuring stations worldwide.
These range from manually operated devices to fully automated, robot-
loaded solutions for inline measurements.
Individual Clamping Concepts

In the simplest case, these can be individual solutions that are equipped
with specially adapted fixtures to securely fix the workpiece with
its partially complex geometry. With simple means, the work for
measurement technicians and machine operators in production is made
simpler and more efficient.
Manual and Semi-Automated Solutions

On the way towards automation, Mahr offers various configurations of
manual axes (linear and rotary axes) that can also be integrated into
existing measuring stations. This makes it possible to further simplify the
often very complex measuring sequences of a standardized measuring
station.
With semi-automated measuring stations, measuring processes can be
accelerated and measurement reliability increased. These measuring
station concepts are characterized by an automated measuring sequence
that guarantees reproducible and comparable measurement series. Setting
up the measuring station for the respective measurement, however, is still
carried out manually by the operator.

CNC Measuring Machines – Fully Automated and Reliable
Our fully automated customer solutions recognize and measure
workpieces automatically, with high precision quickly, and therefore highly
productively. CNC measuring systems based on the MarSurf LD 130,
for example, can check the roughness and contour of small workpieces
with a resolution of 0.8 nm – valve needles, nozzle bodies or spindle
measurements of steering nuts. At the touch of a button, measurements
will be performed fully automated and independent of the operator,
resulting in highly reliable measurement results – even when comparing
production sites worldwide.

For more information, please visit our website: www.mahr.com

Engineered Solutions | Customer-Specific Measuring Technology 617
