Engineered Solutions MarSolution

Standardized Measuring Devices

DESCRIPTION

Mahr’s “MarSolution” product group offers special customized solutions in
dimensional measuring technology – semi and fully automatic measuring
systems that work directly in production. Mahr uses its tried and tested
standard components (Millimar measuring interface, probes and standard
elements) to provide reliable and accurate measuring technology. Always
the right solution for your task. Mahr offers solutions for various sectors
and industries.

Vertical Measuring Device with Pivoting Workpiece Holder Between
Centers

• These measuring devices allow inspection of diameter, length, and
radial and axial runout for rotationally symmetrical parts.
• Available with manual or automatic swivel workpiece holder between
centers.
• Motorized rotation also allows the option of dynamic workpiece
measurement.

Measuring Device with Rotary Table

• Measuring devices with rotary table allow combined external and
internal measurements and automatic radial and axial runout testing.
• This measuring device can also be motorized to enable dynamic
measurements.

Horizontal Measuring Device

• Workpiece holder on V-blocks or between centers, including workpiece
loading table.

• The horizontal measuring devices allow workpieces to be held on
V-blocks or between centers. This system is particularly suitable for
heavy workpieces.

• The workpiece can be inserted in the workpiece holder outside of the
actual measuring station.

For more information, please visit our website: www.mahr.com
