Engineered Solutions MarSolution

Measuring Devices based on Millimar Standard Elements

DESCRIPTION

Versatile
• The versatility of the Millimar standard elements means that the right
solution can be provided, whatever the measurement task at hand.

• Whether outer, inner or length measurements, the Millimar standard
elements can be adapted to the most diverse test requirements, even
with difficult to reach workpiece geometries.

• Due to the compact design of the anvils, a large number of measuring
points can be inspected within a small area of the testpiece.

• The pneumatic lifting mechanisms integrated in the measuring elements
simplify the job of moving the testpiece into the measuring position and
reduce wear to the measuring anvils.

Flexible
• The modular concept using Millimar standard elements throughout the
whole system and a generous amount of travel in the measuring anvils
(up to 20 mm), allow a high degree of flexibility in terms of the variety
of testpieces that can be accommodated.

Precise
• The Millimar standard elements are specially designed for use in the
workshop and are manufactured using a rigorous process. This guaran-
tees that the measuring devices give stable and reliable measurements.
• For example, using measuring anvils fitted with two ball-bearing guides
for supporting the moving part, it is possible to achieve measurement
repeatability in the µm range, if this is required due to the tolerances of
the feature being measured.

Reliable
• All components are long-lasting and low-maintenance due to the use of
rust-proof materials and the selection of appropriate heat treatments.
The use of lifting mechanisms to minimize the effects of friction on
the measuring anvils when the workpiece is inserted, further reduces
component wear.

Economical

• Our systems can either be constructed by the customer from standard
catalog elements, or alternatively, we can provide turn-key solutions.
Whichever option you choose, you can be sure that you are purcha-
sing a system that is tailored to your specific requirements on the most
favorable of terms.
• Below are just a few examples of the many factors that contribute to
the cost effectiveness of the Millimar standard elements:
• Standard elements can be reused: Once manufacture of a particular
type of workpiece has ceased, all standard elements used in the test
equipment can be reused to create new test equipment for a diffe-
rent type of workpiece
• A choice of different mechanisms for guiding the moving part of the
measuring anvils according to the accuracy requirements of the mea-
suring task (optimum value for money)
• Reduction in development and implementation time
• Availability of devices: Our standard elements are manufactured
under standard production conditions and are always available off the
shelf and ready to use

For more information, please visit our website: www.mahr.com
