MarGage 417 C/1

Rectangular Gage Blocks made of Ceramic, Tolerance Class 1

Nominal size Order no. Nominal size Order no. Nominal size Order no.
FEATURES mm mm mm
0.5 4804200 1.5 4804269 41.3 4804758
• Ideal for all applications
• The outstanding features of all 1 4804210 1.6 4804270 50 4804323
ceramic gage blocks from Mahr 1.0005 4804764 1.7 4804271 60 4804324
provide unrivalled flexibility in 1.001 4804211 1.8 4804272 70 4804325
practical use 1.002 4804212 1.9 4804273 75 4804326
1.003 4804213 2 4804274 80 4804327
• Advantages of ceramic: 1.004 4804214 2.5 4804275 90 4804328
– Resistant to impact and 1.005 4804215 3 4804276 100 4804329
breakage. Damage to 1.006 3.5 131.4
measuring surfaces from 4804216 4804277 4804760
scratches or to edges from 1.007 4804217 4 4804278
impact causes minimal burring. 1.008 4804218 4.5 4804279
Sliding ability is retained for 1.009 4804219 5 4804280
longer 1.01 4804220 5.1 4804751
– Extremely wear-resistant. 1.02 4804221 5.5 4804281
The longest life and highest 1.03 4804222 6 4804282
stability of any material 1.04 4804223 6.5 4804283
currently used in measuring
technology. Allows for 1.05 4804224 7 4804284
significantly longer gage 1.06 4804225 7.5 4804285
monitoring intervals 1.07 4804226 7.7 4804752
– Corrosion-resistant. 1.08 4804227 8 4804286
Circonimar is extremely 1.09 4804228 8.5 4804287
resistant to alkalis, acids, 1.1 4804229 9 4804288
oil, grinding fluid and other 1.11 4804230 9.5 4804289
aggressive media even without
protective measures 1.12 4804231 10 4804290
– Coefficient of expansion 1.13 4804232 10.3 4804753
similar to that of steel. 1.14 4804233 10.5 4804291
Therefore there are no usage 1.15 4804234 11 4804292
restrictions, even in extreme 1.16 4804235 11.5 4804293
temperature conditions 1.17 4804236 12 4804294
– Circonimar is non- 1.18 4804237 12.5 4804295
magnetizable, anti-static, anti- 1.19 4804238 12.9 4804754
magnetic and non-conductive.
It does not attract dust or dirt. 1.2 4804239 13 4804296
1.21 4804240 13.5 4804297
Tolerance class 1 1.22 4804241 14 4804298
For high accuracy requirements. 1.23 4804242 14.5 4804299
As reference gage block for the
measuring room. Designed to 1.24 4804243 15 4804300
perform particularly accurate 1.25 4804244 15.5 4804301
measurements. For setting 1.26 4804245 16 4804302
indicating measuring instruments. 1.27 4804246 16.5 4804303
For checking precision gages.
1.28 4804247 17 4804304
• Coefficient of linear 1.29 4804248 17.5 4804305
– 6
expansion: 9.3 x 10 K – 1 1.3 4804249 17.6 4804755
1.31 4804250 18 4804306
1.32 4804251 18.5 4804307
1.33 4804252 19 4804308
1.34 4804253 19.5 4804309
1.35 4804254 20 4804310
1.36 4804255 20.2 4804756
1.37 4804256 20.5 4804311
1.38 4804257 21 4804312
1.39 4804258 21.5 4804313
1.4 4804259 22 4804314
1.41 4804260 22.5 4804315
1.42 4804261 22.8 4804757
1.43 4804262 23 4804316
1.44 4804263 23.5 4804317
1.45 4804264 24 4804318
1.46 4804265 24.5 4804319
1.47 4804266 25 4804320
1.48 4804267 30 4804321
1.49 4804268 40 4804322
