MarGage 417 C/2

Rectangular Gage Blocks made of Ceramic, Tolerance Class 2

Nominal size Order no. Nominal size Order no. Nominal size Order no.
FEATURES mm mm mm
0.5 4804400 1.5 4804469 41.3 4806121
• Ideal for all applications
• The outstanding features of all 1 4804410 1.6 4804470 50 4804523
ceramic gage blocks from Mahr 1.0005 4804765 1.7 4804471 60 4804524
provide unrivalled flexibility in 1.001 4804411 1.8 4804472 70 4804525
practical use 1.002 4804412 1.9 4804473 75 4804526
1.003 4804413 2 4804474 80 4804527
• Advantages of ceramic: 1.004 4804414 2.5 4804475 90 4804528
– Resistant to impact and 1.005 4804415 3 4804476 100 4804529
breakage. Damage to 1.006 3.5 131.4
measuring surfaces from 4804416 4804477 4806122
scratches or to edges from 1.007 4804417 4 4804478
impact causes minimal burring. 1.008 4804418 4.5 4804479
Sliding ability is retained for 1.009 4804419 5 4804480
longer 1.01 4804420 5.1 4806114
– Extremely wear-resistant. 1.02 4804421 5.5 4804481
The longest life and highest 1.03 4804422 6 4804482
stability of any material 1.04 4804423 6.5 4804483
currently used in measuring
technology. Allows for 1.05 4804424 7 4804484
significantly longer gage 1.06 4804425 7.5 4804485
monitoring intervals 1.07 4804426 7.7 4806115
– Corrosion-resistant. 1.08 4804427 8 4804486
Circonimar is extremely 1.09 4804428 8.5 4804487
resistant to alkalis, acids, 1.1 4804429 9 4804488
oil, grinding fluid and other 1.11 4804430 9.5 4804489
aggressive media even without
protective measures 1.12 4804431 10 4804490
– Coefficient of expansion 1.13 4804432 10.3 4806116
similar to that of steel. 1.14 4804433 10.5 4804491
Therefore there are no usage 1.15 4804434 11 4804492
restrictions, even in extreme 1.16 4804435 11.5 4804493
temperature conditions 1.17 4804436 12 4804494
– Circonimar is non- 1.18 4804437 12.5 4804495
magnetizable, anti-static, anti- 1.19 4804438 12.9 4806117
magnetic and non-conductive.
It does not attract dust or dirt. 1.2 4804439 13 4804496
1.21 4804440 13.5 4804497
Tolerance class 2 1.22 4804441 14 4804498
For checking production gages of 1.23 4804442 14.5 4804499
quality IT 6 and IT 7. For setting
indicating measuring instruments 1.24 4804443 15 4804500
and for checking accurate 1.25 4804444 15.5 4804501
dimensions in the jig and tool 1.26 4804445 16 4804502
industry.
1.27 4804446 16.5 4804503
• Coefficient of linear 1.28 4804447 17 4804504
– 6
expansion: 9.3 x 10 K – 1 1.29 4804448 17.5 4804505
1.3 4804449 17.6 4806118
1.31 4804450 18 4804506
1.32 4804451 18.5 4804507
1.33 4804452 19 4804508
1.34 4804453 19.5 4804509
1.35 4804454 20 4804510
1.36 4804455 20.2 4806119
1.37 4804456 20.5 4804511
1.38 4804457 21 4804512
1.39 4804458 21.5 4804513
1.4 4804459 22 4804514
1.41 4804460 22.5 4804515
1.42 4804461 22.8 4806120
1.43 4804462 23 4804516
1.44 4804463 23.5 4804517
1.45 4804464 24 4804518
1.46 4804465 24.5 4804519
1.47 4804466 25 4804520
1.48 4804467 30 4804521
1.49 4804468 40 4804522
