MarGage 417 C/0

Rectangular Gage Blocks made of Ceramic, Tolerance Class 0

Nominal size Order no. Nominal size Order no.
FEATURES mm mm
0.5 4804000 1.5 4804069
• Ideal for all applications
• The outstanding features of all 1 4804010 1.6 4804070
ceramic gage blocks from Mahr 1.0005 4804759 1.7 4804071
provide unrivalled flexibility in 1.001 4804011 1.8 4804072
practical use 1.002 4804012 1.9 4804073
1.003 4804013 2 4804074
• Advantages of ceramic: 1.004 4804014 2.5 4804075
– Resistant to impact and 1.005 4804015 3 4804076
breakage. Damage to 1.006 3.5
measuring surfaces from 4804016 4804077
scratches or to edges from 1.007 4804017 4 4804078
impact causes minimal burring. 1.008 4804018 4.5 4804079
Sliding ability is retained for 1.009 4804019 5 4804080
longer 1.01 4804020 5.5 4804081
– Extremely wear-resistant. 1.02 4804021 6 4804082
The longest life and highest 1.03 4804022 6.5 4804083
stability of any material 1.04 4804023 7 4804084
currently used in measuring
technology. Allows for 1.05 4804024 7.5 4804085
significantly longer gage 1.06 4804025 8 4804086
monitoring intervals 1.07 4804026 8.5 4804087
– Corrosion-resistant. 1.08 4804027 9 4804088
Circonimar is extremely 1.09 4804028 9.5 4804089
resistant to alkalis, acids, 1.1 4804029 10 4804090
oil, grinding fluid and other 1.11 4804030 10.5 4804091
aggressive media even without
protective measures 1.12 4804031 11 4804092
– Coefficient of expansion 1.13 4804032 11.5 4804093
similar to that of steel. 1.14 4804033 12 4804094
Therefore there are no usage 1.15 4804034 12.5 4804095
restrictions, even in extreme 1.16 4804035 13 4804096
temperature conditions 1.17 4804036 13.5 4804097
– Circonimar is non- 1.18 4804037 14 4804098
magnetizable, anti-static, anti- 1.19 4804038 14.5 4804099
magnetic and non-conductive.
It does not attract dust or dirt. 1.2 4804039 15 4804100
1.21 4804040 15.5 4804101
Tolerance class 0 1.22 4804041 16 4804102
For maximum accuracy 1.23 4804042 16.5 4804103
requirements. To be used as basic
standards in test laboratories 1.24 4804043 17 4804104
and precision inspection rooms, 1.25 4804044 17.5 4804105
where other gage blocks and high 1.26 4804045 18 4804106
accuracy measuring instruments 1.27 4804046 18.5 4804107
are calibrated.
1.28 4804047 19 4804108
• Coefficient of linear 1.29 4804048 19.5 4804109
– 6
expansion: 9.3 x 10 K – 1 1.3 4804049 20 4804110
1.31 4804050 20.5 4804111
1.32 4804051 21 4804112
1.33 4804052 21.5 4804113
1.34 4804053 22 4804114
1.35 4804054 22.5 4804115
1.36 4804055 23 4804116
1.37 4804056 23.5 4804117
1.38 4804057 24 4804118
1.39 4804058 24.5 4804119
1.4 4804059 25 4804120
1.41 4804060 30 4804121
1.42 4804061 40 4804122
1.43 4804062 50 4804123
1.44 4804063 60 4804124
1.45 4804064 70 4804125
1.46 4804065 75 4804126
1.47 4804066 80 4804127
1.48 4804067 90 4804128
1.49 4804068 100 4804129
