Stripping tool for PEX insulation on medium voltage cable

FBS1723

Stripping tool for stripping PEX insulation on medium voltage cable.

Properties:
• FBS1723 contains the stripping tool, 100 g silicone paste and instructions for
use in a padded plastic box
• the tool is easy to use - rotate the tool with the handle
• stripping can be done from Ø 15 to 52 mmm which corresponds to cable 12 kV
50-1000 mm², 24 kV 25-1000 mm², 36 kV up to 630 mm² and 52 kV up to 500 mm²
• depth of the blade can be adjusted from 0 to 15 mm
• unlimited stripping length
• the cutting blade is available as a spare part
• adjustable feed in 5 positions, the blade is hardened, min HRC 55, and specially
ground and very easy to replace

Max ø Net weight Length
conductor Name (kg) mm Width Height
15-52 FBS1723 1,072 275 220 65

FBS1723 comes with box, silicone paste and
instructions for use.

Accessories for FBS1723
Spare parts for the FBS1723 stripping tool.
RS = spare blade and SP = silicone paste.
Net weight
Name
(kg)
FBS1723RS 0,001
FBS1722SP 0,115
