Tool for cutting and stripping conductors 0.5 - 6 mm²

and cutting up to Ø 20 mm²

SCT001
Stripping and cutting tool for cutting and stripping conductors 0.5 - 6 mm².

Properties:
• material: high-quality steel
• cuts 0.5-6 mm² (20-10 AWG)
• strips 0.5-6 mm² (20-10 AWG)
• light and versatile
• lockable setting
Max ø Net weight Length
mm² AWG Name Width Height
conductor (kg) mm
0,5-6 2 10-20 SCT001 0,102 140 65 10

CT10
Cable cutter for cutting cable up to approx. Ø 10 mm.

Properties:
• cuts Cu and Al cable up to approx. Ø 10 mm
• not intended for cutting steel
• small and manageable
• tempered forged steel cutting blade
• design of the blade inserts provides a clean cut surface
Max ø Name Net weight Length Width Height
conductor (kg) mm
10 CT10 0,16 165 50 15

CT20
Cable cutter for cutting cable up to approx. Ø 20 mm².

Properties:
• cuts Cu and Al cable up to approx. Ø 20 mm
• not intended for cutting steel
• sturdy and comfortable handle grip

• tempered forged steel cutting blade
• design of the blade inserts provides a clean cut surface
Max ø Net weight Length
conductor Name (kg) mm Width Height
20 CT20 0,471 240 78 21

UP-B41
Cable cutter for cutting cable up to approx. Ø 15 mm.

Properties:
• cuts multi-stranded Cu and Al conductors.
• not intended for cutting steel
• small and manageable

• high quality, professional tool
• design of the blade inserts provides a clean cut surface
• minimal power requirement
Max ø Net weight Length
mm² AWG Name Width Height
conductor (kg) mm
95 15 4/0 UP-B41 0,357 255 25 70
