WORKBENCHES AND PRESSES
EQUIPMENT
Workbenches and Tables
®
BPWORKBENCH Heavy-Duty Workbench (Blue-Point )
• Full bottom shelf and superior powder-coat finish
• Net weight: 139 lb
• Weight capacity: 1,200 lb
• Top panel: 13-gauge steel
• Bottom shelf: 13-gauge steel
BPWORKBENCH • Steel support: 12-gauge steel
• 60-1/16ʺ W x 30-3/4ʺ D x 34-1/16ʺ H
EQ2311DT Teardown Benches
• Ideal for working on transmissions, small engines
and hydraulic components
EQ2311DT • Reinforced work surface will stand up to years
of heavy use
• Top has a 3/4ʺ high retaining lip on all sides tapering
to the rear center to a 1/2ʺ threaded and plumbed drain
• Optional caster kit consists of (4) swivel 7-1/2ʺ H casters
• 1/2ʺ threaded drain nipple allows for connection
of hose for fluid capture
EQG2223K5 Open Leg Workbench
• Constructed from heavy 12 ga. steel with die formed legs
EQG2223K5 welded into a one piece unit for superior strength
• Includes a storage drawer for mounting on an end
or at the center of the bench
SHOP EQG245U5 EQG245U5 Pedestal Workbench ®
• 5ʹ W x 29ʺ D x 33-1/2ʺ H
• Manufactured with a heavy 12-gauge top surface
and an integral back flange
• Four drawer pedestal is designed with roller drawer
rails for smooth, non-binding operation
• 5ʹ W x 27-1/2ʺ D x 34-1/8ʺ H
BPWKBNCHX Heavy-Duty Workbench (Blue-Point )
• Heavy-duty 2,000 lb capacity (bench top 1,300 lb; lower
shelf 700 lb)
• Adjustable legs with four work surface height options—
adjust to 30, 33, 36ʺ (shipping height) or 40ʺ
• Optional storage drawers are sold separately
• Snap-on Slots-N-Dots on the side panels
™
®
• Side and back panels can be installed flush or 1-1/4ʺ
above the work surface
BPWKBNCHX • Features 6 x 2ʺ swivel-lock casters
• Overall size: 74ʺ W x 32ʺ D x 40ʺ H
• Net weight: 251 lb
BPWKBNCHX-1 Shallow Wide Drawer (Blue-Point )
®
• Optional accessory for the BPWKBNCHX Heavy-Duty
Workbench (Blue-Point )
®
• Overall size: 20.5ʺ W x 27.4ʺ D x 4.3ʺ H
• Net weight: 14.5 lb (including slides)
®
BPWKBNCHX-2 Deep Narrow Drawer (Blue-Point )
• Optional accessory for the BPWKBNCHX Heavy-Duty
®
BPWKBNCHX-1 BPWKBNCHX-2 Workbench (Blue-Point )
• Overall size: 14.6ʺ W x 27.4ʺ D x 9.1ʺ H
• Net weight: 16.7 lb (including slides)

3-Ton Arbor Press
Specifications CG100 CG100 3-Ton Arbor Press
Dimensions 11-1/8ʺ W x 18ʺ H • Frame is 2ʺ steel channel—bolts to workbench
Pressure, tons 3 • Gearing multiplies handle pressure up to 3-ton force
Base Size 11-1/8 x 6-1/8ʺ • Set includes arbor press frame, utility punch, work block
Vertical Capacity 12-3/4ʺ and adaptor to convert 1/2ʺ drive to 5/16ʺ round drive
Opening Width 9ʺ • Optional accessories: The adaptors from A57Q bushing
Width Between driver set can be used with CG100-16 5/16ʺ round drive
Work Brackets 9ʺ adaptor—the CJ951 bearing separator fits neatly between
Pressure Shaft 9ʺ (when utility punch the work support brackets
Stroke is attached)
CG100-14 Utility Punch
836 CG100
