C-CLAMPS
EQUIPMENT
Medium-Duty C-Clamps
• Maximum strength ribbed iron frame
• Steel screw with full standard threads and sliding T-handle
• Large anvil and steel swivel pad to ensure secure clamping
• Deep throat style
Stock No. Throat Depth, inches Capacity, inches Spindle Dia., inches
CL537A 3-1/2 2 5/16
CL546A 6-1/4 2-1/2 3/8
CL537A

VISES

Utility Vises
• Regular duty utility vises can be used for a variety
of shop applications
• Replaceable serrated jaws, built-in pipe jaws, swivel base
and large anvil to handle a variety of jobs Throat Depth,
SHOP WV676 WV648 4-1/2 7-1/2 1/8–2-1/2 3-11/16
Maximum
Pipe Capacity,
Jaw Width,
Stock No.
inches
inches
Opening, inches
inches
8
4-1/2
1/8–3
6
6
4-1/4
1/8–3
WV656
3-3/4
2-5/8
1/8–2
WV674
3-7/16
1/8–2
5-1/2
4-3/4
WV675
5-3/4
6-1/2
WV676
High-Visibility Safety Vises
• Coated in High-Visibility yellow, which conforms to the OSHA
safety color standard for physical hazards regulation #1910.144
• Powder-coat finish resists scratches and gives a tough, durable
finish
• Handles and lockdowns are black oxide coated for additional
corrosion resistance
• Units feature a straight-line design with a totally enclosed
spindle and nut, replacement pipe and serrated vise jaws
• 360° swivel base
Jaw Width, Maximum Opening,
WV1560VIS Stock No. inches inches Pipe Capacity, inches
WV1550VIS 5 5-1/4 1/4–2-1/2
WV1560VIS 6 5-3/4 1/4–3-1/2
Pipe and Bench Vises
• Large anvil, totally enclosed spindle and nut
• 60,000 PSI high-ductile iron for the main stress parts
• Replaceable steel vise jaw inserts and milled steel pipe jaws
• Alloy steel slide bar
Maximum
Jaw Width, Pipe Capacity, Throat Depth,
Stock No. Opening,
inches inches inches
inches
WVC3 6 9 3/8–6 6-5/8
WVC3
834

Snapon.com 1.877.762.7664
