AIR CONDITIONING: SERVICE EQUIPMENT AIR

ACTR4151A ACTR5134A
ACTR4131A
ACTR5150A
Digital Manifold Gauges (R134a) Manifold Test Gauges (R134a)
ACTR4772-2
ACTR5150A ‡ Digital Manifold Gauge Set ACTR4131A ‡ A/C Manifold Gauge Set
(R134a) (Blue-Point ) • Anti-flutter gauges smooth-out needle movement ACTR4772-3
®
• Displays refrigerant and oil capacities • Easy-grip all-metal side-mounted knobs
• Large easy-to-read LCD screen displays • Piston-type free-floating valves reduce O-ring wear
pressure and vacuum readings for R134a • Manual R134a couplers ®
• High-quality aluminum block manifold • 60ʺ red, blue and yellow inner nylon layer hoses meet EPA, SAE
®
• Performs system leak check at the and UL standards
conclusion of the evacuation process • Yellow hose includes shut-off valve CONDITIONING
• Heavy-duty hook folds and stores ACTR4151A ‡ Manifold Gauge Set
on the back • Manual couplers are spring loaded to eliminate service valve damage
• Rubber boot for added protection • Extruded aluminum body with solid brass fittings
• Includes digital manifold, (3) 72ʺ hoses • High- and low-side silicon anti-flutter gauges (65 mm) reduce vibration
and (2) manual couplers in a storage case • Sight glass permits visual monitoring of refrigerant flow
• 96ʺ yellow charging hose, plus 72ʺ red and blue hoses
ACTR5134A ‡ Premium Manifold Gauge Set
• Extra-large
• 80 mm gauge face and oversized sight glass for better visibility
• Large 1/4 turn open/close manifold ball valves
• Manual high and low couplers for quick connections
• 72ʺ red and blue nylon barrier hoses meet EPA, SAE and UL standards
®
®
• 96ʺ yellow charging hose
ACTR4772-2 ‡ Low-Side Quick Coupler
ACTR4772-3 ‡ High-Side Quick Coupler

ACTR9600 ACT51234A ACTR1234YF
Heavy-Duty Manifold Test Gauges Manifold Test Gauges (R134a/R12)
ACTR9600 ‡ Heavy-Duty Truck/Bus ACT51234A ‡ Dual Refrigerant Manifold Test Gauge (R12/R134a)
Manifold Gauge Set • Three sets of hoses (72ʺ red and blue, plus 96ʺ yellow) permit true
• Heavy-duty A/C manifold for large trucks, interchange between R12 and R134a refrigerants
buses and reefer applications • Large 1/4 turn positive open/close manifold ball valves
• Larger profile aluminum block • Oversized sight glass for easy-flow viewing
versus smaller import blocks on • Extra-large 80 mm gauge face for better visibility
competitive units • Manual high and low couplers for quick connections
®
®
®
• Heavy-duty conversion couplers • Nylon barrier hoses meet EPA , SAE and UL standards
for durability • Extra access port for a vacuum line
• Couplers are spring-loaded to prevent ACTR1234YF ‡ 1234YF Manifold Gauge Set
damage to valve cores • For vehicles using new 1234yf refrigerant
• Silicon-dampened gauges for durability • Red and blue nylon barrier hoses with 12 mm male fittings on both ends
• Extra-long 96ʺ Goodyear hoses • R1234yf high- and low-side couplers
®
for added reach; (1) each in red, ACTR1234YF1 ‡ 1234YF High-Side Coupler
blue and yellow • For vehicles using new 1234yf refrigerant
ACTR1234YF2 ‡ 1234YF Low-Side Coupler
• For vehicles using new 1234yf refrigerant
• Wear safety shield (user and bystander) 733
• ‡ These products can expose you to chemicals which are known to the state of California to cause
cancer and reproductive harm. See pages 906-907 for details.
• Read safety precautions on pages W1 to W4
