AIR CONDITIONING: SERVICE EQUIPMENT (R134A, R12, R1234YF)
CONDITIONING

Valve Core Tools
ACT1297 ‡ Master Valve Core Tool Set (R134a/R12)
• High side GM /Ford R12 adaptor (1/4 x 3/16ʺ)
®
®
• High side Ford R12 adaptor (1/4 x 1/8ʺ)
®
®
• GM large bore valve core remover/installer assembly
• JRA R134a valve core remover/installer assembly
• Eton R134a low side valve core remover/installer assembly
• Eton R134a high side valve core remover/installer assembly.
Valve assembly enables changes under pressure
• R134a high side connector (16 mm)
• R134a low side connector (13 mm)—1/4ʺ FL swivel connector
• Plastic box for set component storage
ACT1297 ACT2105 ‡ Orifice Tube Service Kit
• Installs and removes any style orifice tube
• Removes broken screens and tubes
• Includes an auger point shaft puller, for GM vehicles, brass
®
extension, puller, remover arbor, remover nut and a storage case
ACT1298 1234yf Remover/Installer Kit
• Valve core remover/installer for R1234yf vehicles
• Removes valve cores with no refrigerant loss
ACT1298
• Ball valve construction for years of reliable service
ACT2105 • 17 and 14 mm high- and low-service couplers
• Covers all 1234yf valve cores
Can Tapper Valve
ACT413A ‡ Side Mount Can Tap Valve
• Fits R134a (2 7/8ʺ), R12 (2-1/2ʺ) and oil (2ʺ) US standard
charge cans
• Includes 1/2ʺ ACME-M and 1/4ʺ FL-M ports
AIR • Composite construction with brass ports
• Internal safety check valve prevents system backflow
ACT413A
• Includes an insert for smaller cans
• Locking handle provides constant pressure
Seal and Clutch Service
ACT1300B ‡ A/C Clutch Remover Set
• Simplifies removal/installation of A/C compressor clutch
and clutch plates
• Provides access to shaft seals
®
®
• For use with Ford , Chrysler and GM vehicle A/C
®
compressors
• Includes an adjustable spanner wrench
ACT1300B
AIR CONDITIONING: SERVICE EQUIPMENT (R134A, R12, R1234YF)

Oil and Dye Injectors
ACTR82375 ‡ 2 oz Oil Injector (R134a only)
• Used to add refrigerant oil or large amounts of UV leak-detection dyes
to A/C systems
• Quickly adapts to manifold gauge sets or charging equipment
• 1/2ʺ ACME male x 13 mm R134a low side female threads
ACTR82375
• 2 oz capacity
• For R134a use only
ACT53134A ‡ Oil Injector (Blue-Point )
®
• Great for use on standard and hybrid R134a systems
• Any dye/oil can be put into the AC53134A and injected into the system
• Dye/oil can be injected while the system is under a vacuum, or against
ACT53134A
the pressure while the system is full and running
• Heavy-duty anodized aluminum construction for years of reliable use
• Injection measurements are 1/10 oz for concentrated dye, 1/4 oz for
standard dye and ml
®
ACT53135 ‡ R1234yf Refill Dye/Oil Injector (Blue-Point )
• Refillable oil/dye injector for R1234yf vehicles
ACT53135 • Heavy-duty aluminum construction for years of reliable performance
736 • Complete with a R1234yf low side coupler
• Easy twist-style injector for accurate measurements
Snapon.com 1.877.762.7664
