WHEEL BALANCING: MOTORCYCLE WHEEL BALANCER AND TIRE CHANGER

Motorcycle Wheel Balancer
EEWB333B Motorcycle Wheel Balancer
• Hand spin operation features static and dynamic
balancing modes
• Features five ALU modes to place weights in the proper
location on multiple wheel configurations EEWB333B
• Input of rim distance by SAPE arm for accelerated set-up time UNDERCAR
• Cycle time of 6–10 seconds
• Allows exact weight placement on rim when using
tape weights
• Small footprint takes up a minimum of floor space Specifications EEWB333B
• Weight minimization and balancing optimization modes for Weight Imbalance Resolution
reducing the overall weight usage (roundoff mode), oz (g) 0.25 (5)
• Split weight mode to hide weights behind spokes Cycle Time, seconds 15
• Stadium weight tray is curved allowing for easy access to the Measuring Speed, RPM 100
keypad and weight pockets Rim Width, inches (mm) 3–20 (508)
• Multiple operator feature allows several users to quickly
recall settings Rim Diameter, inches (mm) 8–30 (203–762)
• Virtual plane imaging technology for unsurpassed accuracy Max Wheel Width, inches (mm) 20 (508)
• Clamps the tire to keep it true to the balancer shaft center Max Tire Diameter, inches (mm) 42 (1,067)
without movement Electrical Requirements, V AC/ph/Hz/A 115/1/60/4
• Adaptor comes complete with 14 mm shaft, 3/4ʺ adaptors, Required Work Area (W x D), 52 x 48 (1,321 x 1,219)
cones and spacers inches (mm)
• Serviced on site with a two year parts and labor warranty Machine Weight, lb (kg) 309 (140)

WHEEL BALANCING: ACCESSORIES

Wheel Balancing Accessories
WWH13LG Wheel Weight Hammer EAA0260D80A Optional
(Blue-Point ) Motorcycle Adaptor For Snap-on
®
®
• Designed for use on steel and zinc Wheel Balancers
clip-on wheel weights • Holds wheel and tire assembly
• Soft hammer face to avoid scratches into position
and dings • Minimizes wobble and WWH13LG WWH13SM
• Solid handle resists most shop improves accuracy
chemicals and has a nonslip grip EAA0277D03A 10 mm
*
• Replaceable cold-rolled steel hook
assembly to ensure long service life Shaft Assembly
• Works best on domestic brands • 10 mm shaft assembly
*
that use traditional dimension EAA0277D05A Scooter Adaptor
dismount holes • Scooter adaptor
*
®
WWH13SM Wheel Weight Hammer EAA0277D07A Suzuki , Moto
®
(Blue-Point ) Guzzi V11 14 mm Shaft Cone set
®
®
®
• Designed for use on steel and zinc • Suzuki , Moto Guzzi V11 14 mm
clip-on wheel weights shaft cone set
®
®
• Soft hammer face to avoid scratches EAA0277D20A Ducati /Triumph WWPR13A
*
and dings Adaptor Set
• Solid handle resists most shop • Ducati /Triumph adaptor set
®
®
chemicals and has a nonslip grip EAA0277D22A Harley-Davidson EAA0260D80A
*
®
• Replaceable cold-rolled steel hook
assembly to ensure long service life 3/4ʺ Shaft Adaptor – 311.2 mm Long
®
• Specially designed small diameter • Harley-Davidson 3/4ʺ shaft adaptor
dismounting hook is used on wheel • 311.2 mm long
®
*
weights with smaller dimension EAA0260D16A BMW Adaptor for
dismount holes Monolever Wheels EAA0277D03A
®
WWPR13A Wheel Weight Pliers • BMW adaptor for monolever wheels
®

®
• Easily removes and replaces EAA0277D09A Honda /Yamaha
wheel weights, as well as cutting Monolever Adaptor Flange
and crimping • Honda /Yamaha monolever
®
®
• Made of heat-strengthened steel adaptor flange
• Comfortable vinyl handle grips and EAA0277D11A Aprilia Monolever
®

replaceable hard plastic hammer tip
Adaptor Flange
• Aprilia monolever adaptor flange
®
*Requires EAA0260D80A Adaptor
EAA0277D22A EAA0260D16A
675
• Read and follow all safety messages and instructions
• Read safety precautions on pages W1 to W4
