TIRE AND WHEEL: TIRE PRESSURE MONITORING SYSTEM
UNDERCAR

TPMS Tools
TPMS3BOX TPMS Sensor Bench Tester
• Tests TPMS sensors without having to mount in a tire/wheel assembly
• Pressurizes the sensor to simulate actual conditions
• For use with Tire Pressure Monitoring System tools
• Saves time in mounting/dismounting the tire
TPMS3U TPMS3 Software Update
• Includes up to the current model year vehicle coverage: sensor testing, relearn
procedures and ECU sensor ID registration
• Troubleshooting menu option assists the technician diagnosing the TPMS
• Improved menu navigation with guided symptom-based TPM sensor tests and
system relearn procedure
TPMS3BOX ® ® ®
• Added ECU unlock for Toyota , Lexus and Scion vehicles that have a TPMS
dash-reset button
• Part number lookup for OEM and aftermarket sensors
• Software purchase allows user to access new updates for a period of 12 months
TPMS3PRG Programmable Sensor Add-on Package
• Programs aftermarket tire pressure sensors
• Used for replacing a sensor with low battery life or one that is non-functioning
• Reduces sensor inventory costs—one sensor covers multiple
vehicle applications
• Use to install a duplicate set of sensors in a summer/winter set of tires
®
• Consists of a 2 GB microSD card, along with a registration certificate
TPMS3U • Registration certificate contains a code that is entered into webTPM and allows
access to sensor programming functionality
• Requires TPMS3 software version CS2-02 or newer to install TPMS3PRG
• TPMS3PRG is a one-time activation to program aftermarket TPM sensors
®
• Works with the following aftermarket programmable sensors: Alligator
®
™
®
sens.it , BWD Standard QWIK-SENSOR , Dorman DIRECT-FIT, EZ-sensor ,
®
®
®
™
™
®
®
®
®
Dynamic DVT Pro Select , Hamaton UPro, Huf IntelliSens , NAPA Echlin
®
®
QWIK-SENSOR , Orange SIMPLE SENSOR and Steelman Select Sensor
®
™
TPMS4U TPMS4 Software License
• Includes up to the current model year OE vehicle coverage, with the
addition of new vehicle protocols, increased sensor testing coverage and
TPMS3PRG
new relearn procedures
®
• Added current model year new vehicle platform coverage, such as Chrysler
®
®
300, BMW , Honda , Lincoln , Lexus , Mazda , Mercedes-Benz , Sprinter ,
®
®
®
®
®
TPMS4U
Mitsubishi , Subaru and Toyota ®
®
®
• New aftermarket sensor addition the MAX T.O.T.A.L. Gen 2 Sensor
• Updated aftermarket sensor coverage for the following sensors: Alligator
®
®
®
Sens.It , Schrader EZ sensor , HUF Intellisens UVS and ECS, Hamaton
®
®
®
®
TPMS4 Software License
™
®
®
Licencia de software TPMS4 U-Pro, Mobiletron , Orange Universal, BWD Standard QWIK-SENSOR ,
Licence logicielle TPMS4
®
®
NAPA QWIK-SENSOR , Steelman Select, PDQ Programmable, MAX T.O.T.A.L
™
Gen 1 Sensor; Dynamic Pro-Select and Mobiletron Universal
®
2019-Q1
• Part number lookup for OEM and aftermarket sensors
• Trailer TPMS coverage: TPMS by Dill Valve and Retrofit by Schrader ®
• Provides the user with a registration code to download the update through
TPMS4U TPMSconnect portal
• Software purchase allows the user to access new updates for a period of
12 months
QDTPMS S61112 SDMV208
QDTPMS Valve Core Torque Tool S61112 1/4ʺ Drive 6-Point Metric SDMV208 Tire Valve Bit
®
• Specifically designed to be used 11 and 12 mm TPMS Flip Socket • Designed for use with all Snap-on
as a core remover and precise • Manufactured from special alloy ratcheting screwdrivers
installer for TPMS tire valves steel, precision forged and heat • Similar to what is covered by the
to eliminate risk of damaging treated for optimum strength TR107A, TR108, TR117O screwdrivers
expensive TPMS sensors and durability • 1/4ʺ Hex insert bit, 1ʺ length
• Preset to 4 in-lb to prevent over- • Requires a 1/4ʺ drive extension
or under-torquing • Used to remove and install clamp-in-
• Preset torque setting also helps style TPMS sensors—combined with
prevent valve core leaks that a torque wrench, this socket allows
lead to low tire pressure and the technician to precisely install
TPMS alerts clamp-in-style TPMS sensors
