WHEEL BALANCING: ACCESSORIES
UNDERCAR

EAK0309J54A

EEWB3-1B
8100068

EAA0255J33A

EAK0309J61A
EEWB3-4A

Balancer Pin Plate Kits
Stock No. Description EEWB3-1A Stock No. Description EEWB3-4A
EEWB3-11B Adaptor Plate #1 • EEWB3-42A #1 Collet 48.3–61.0 mm 1
EEWB3-12B Adaptor Plate #2 • EEWB3-43A #2 Collet 55.9–68.6 mm 1
EEWB3-13B Adaptor Plate #3 • EEWB3-44A #3 Collet 63.5–76.2 mm 1
EEWB3-14B Adaptor Plate #4 • EEWB3-45A #4 Collet 71.1–83.8 mm 1
EEWB3-02B Wide Taper Pin B 8X EEWB3-46A #5 Collet 78.7–91.4 mm 1
EEWB3-03B Round Pin C 6X EEWB3-47A #6 Collet 86.4–99.1 mm 1
EEWB3-08 Small Taper Pin E 8X EEWB3-48A #7 Collet 94.0–106.7 mm 1
EEWB3-49A #8 Collet 101.6–114.3 mm 1
EEWB3-1B Balancer Plate Pin Kit EEWB3-50A #9 Collet 109.2–121.9 mm 1
• Pin plate kits are a system of plates and studs to center
and load the wheel at the lug stud holes EEWB3-4A 9 pc Collet Set
• Used to properly mount wheels to the wheel balancer • Precision-machined and sized collets fit into the rear
and is positioned outside of the wheel, in-between the pilot hole on plastic-clad wheels to avoid damage
quick nut and lug stud holes • Collets are shallow in length—to not interfere with
• Mirrors mounting the wheel to the vehicle’s hub and plastic clad wheels
minimizes imbalance errors • Recommended to be used in conjunction with a pin plate
• Applies even pressure to lug stud surfaces and locates on the wheel’s outer side
the wheel on center of balancer shaft • Larger collets require the use of the EAK0309J54A
• Avoids misalignment by improper and inconsistent Balancer Flange Spacer
mounting on the balancer ®
• Eliminates damage to plastic clad wheels EAA0255J33A 40 mm Shaft Upgrade Kit (Blue-Point )
• Converts older Snap-on balancers with a 28.5 mm shaft
®
EAK0309J54A Balancer Flange Spacer to 40 mm (EEWB304A and B, EEWB305A and B)
• Provides added clearance for larger cones and collets
• For use with the EEWB3-4A Collet Set EAK0309J61A Storage Stand
• Storage stand for EEWB3-1B and EEWB3-4A
8100068 2 pc Truck Step Cone Kit
• Low taper angle for hub centric wheels
• Used for 4.25–6.85ʺ hub pilot hole sizes
• Works on wheel balancers with a 40 mm shaft size
• Spacer allows for additional clearance
