DENT PULLERS/ACCESSORIES

Stud Gun Dent Pullers
YA22345 Stud Gun YA223454 T-Puller
YA22345KT Stud Gun Dent Puller Kit • Compact for small damage repair on
• Kit includes a stud gun, welding tips, lightweight metal
slide hammer and T-puller • Helps reduce overpull
• Used to pull dents by welding pins to YA223455 Slide Hammer
the work piece • Polished steel bar with a rubber handle
• Stud gun uses minimal heat to reduce ensures positive pulling action YA22345KT WELDING
burn through YA223456 Shrinking Electrode
YA223451 Draw Pins (2 mm) • Provides fast heat
• Soft for easy flexing and grinding YA223457 Pin Electrode
• Delivers 500 lb pull • Holds all standard size pins
• Pack of 500 YA223458 Trim Rivets
YA223452 Draw Pins (2.5 mm) • Used to repair metal trim strips
• Soft for easy flexing and grinding • Weld onto a panel and provide
• Delivers 500 lb pull permanent retention to a trim strip
• Pack of 500 • Pack of 500 YA223453
YA223453 Magna Clamp YA223459 Rivet Electrode
• Features a wing nut and is • For use with YA223458 Trim Rivets
self-tightening • Retains a trim rivet for welding
• Locks onto draw pins for YA2234510 Storage Case
pulling dents • For YA22345KT Stud Gun Dent Puller Kit

YA22350C

Portable Dent-Pulling System
• Easily pulls dents on roofs, hoods and side panels
• Star tip design eliminates the need to drill holes or cut pin heads YA22375
• Built-in slide hammer speeds up the pulling process (YA22350C only)
Power Input Power Lead Ground Cable Shipping
Stock No. Type Primary Voltage Line Fuse
Cable, feet (m) Length, feet Length, feet Weight, lb
YA22350C ‡ Star Tip 120 V AC, 50/60 Hz 30 A 25 (7.6) 7 7 64
YA22375 ‡ T-Handle 120 V AC, 50/60 Hz 30 A 25 (7.6) 10 7 64
YAH22350C ‡ Star Tip 208/230 V AC, 50/60 Hz 30 A 25 (7.6) 7 7 64
YAH22375 ‡ T-Handle 208/230 V AC, 50/60 Hz 30 A 25 (7.6) 7 7 64

Portable Dent Puller Accessories
YA2235CART Accessory Cart
• Adds additional height and portability
YA2355 Star Tips
• Replacement tips (10 pk) for YA22350C,
YAH22350C and YA223005
YA2355
YA2351 ‡ Welding Tip
• Optional long stud welding tip
YA2353 ‡ Heating Tip
• Replacement heat shrink heating tip
YA2354 ‡ Slotted Weld Tip
• For use with a portable dent pulling system YA2353
YA2358 Magnetic Base
• Replacement magnetic ground clamp
YA22357 Trigger Switch
• Replacement switch YA2235CART
YA223008 Prybar
• Replacement prybar for YA22375 and AH22375;
optional for YA22350C and YAH22350C YA2358

• Wear welding helmet and protective clothing while welding and cutting
• Do not allow bystanders while welding and cutting 671
• ‡ These products can expose you to chemicals which are known to the state of California
to cause cancer and reproductive harm. See pages 906-907 for details.
• Read safety precautions on pages W1 to W4
