Page 654 - 实耐宝完整US版1500

SNAP-ON MUSCLE MIG/MIG WIRE FEED WELDERS
®
WELDING surpasses the competition. Ideal for many applications, including automotive repair, collision, heavy-duty truck, farm and
®
Snap-on 230 V MIG Welders
®
Snap-on MIG Welders have higher duty cycles at maximum amperage, providing added weld times and performance that
metal fabrication shops. Added capabilities include a detachable feeder assembly, spot stitch (some models), along with
the optional TIG accessory and aluminum spool gun packs.

Wire feed assembly, constructed of
precision-machined cast aluminum,
features all-metal gearing and 800
in/min delivery for consistent wire
speeds
All-copper-wound, tapped
®
transformer features Nomex
insulation and bolted laminations
to provide precise voltage control
Capacitor bank and diode set
delivers consistent voltage and and repeatable welds
industry-leading smooth arc
characteristics

MM250SL

MIG220
MM350XL
®
Snap-on 230 V MIG Welders
Specifications MIG220 MM250SL MM350XL
Output Amperage Max, amps 220 270 350
Duty Cycle Rating 60% @ 185 A 100% @ 185 A 100% @ 300 A
Welding Capacity, Single Pass, inches 5/16 3/8 1/2
Voltage Settings, MIG/TIG 12/4 8/4 8/4
Spot-Stitch No Yes No
Detatchable Feeder No Yes Yes
Wire Size, inches 0.023–0.045 0.023–0.045 0.023–0.063
Torch Length, feet 10 10 12
Feeder Cable Length, feet N/A 15 15
Ground Cable Length, feet 10 15 25
Power Input Cable Length, feet 20 20 20
Input Voltage 208/230 V AC, 50/60 Hz 1-ph 208/230 V AC, 50/60 Hz 1-ph 208/230 V AC, 50/60 Hz 1-ph
Input Amperage (recommended) 26/24 26/24 46/42
Gas Regulator-Flowmeter Yes Yes Yes
Warranty* 2 Year 2 Year 2 Year
*Does not include cable or torch.
