FUEL AND ENGINE SYSTEMS: OXYGEN AND FUEL SENSOR TOOLS

Sensor Tools
S6176 1/2ʺ Drive Metric 22 mm Oxygen Sensor Socket
®
®
®
• For service on most Nissan , Mazda , Honda and Acura vehicles
®
• Slotted side clears projections S6176
• 3-7/8ʺ long
S6150 1/2ʺ Drive 12-Point 7/8ʺ Oxygen Sensor Crowfoot Wrench TESTING
• Special crowfoot wrench design provides the strength necessary
for removal/installation
• 1/2ʺ drive, 12-point, 7/8ʺ wrench size
• Nickel-chrome finish
S6154 1/2ʺ Drive 12-Point 22 mm Oxygen Sensor Wrench
®
• For use on oxygen sensors on 2007 Acura RDX ® S6150
• 1/2ʺ drive, 12-point, 22 mm wrench size
• Nickel-chrome finish
SWR1A Oxygen Sensor Wrench
• Designed for all oxygen sensors with a 7/8ʺ hex
• Flex head offers essential clearance for removal/installation of &
oxygen sensors when a sensor is positioned upward and inward to
the floorboard or when leverage is needed around an exhaust pipe S6154
• Ford Contour and Ford Modular 4.6 L and 5.4 L engines used in
®
®
trucks and SUVs have this application
• Other applications include 7/8ʺ and 22 mm knock sensors used on
midsize trucks, SUVs and vans SWR1A
• Flank Drive wrenching system for greater applied torque
®
• Chrome finish for easy cleanup and protection against corrosion
• Compact, low clearance head
• Overall length: 10-3/4ʺ; hex: 6-point 7/8ʺ; 1-9/16ʺ head diameter
• Slot width: 1-5/16ʺ
SWR2 Oxygen Sensor Socket
• For oxygen sensors located in the exhaust manifolds of 1981–later
cars and light trucks, including VW ®
• 3/8ʺ drive with 7/8ʺ hex size
• 1/2ʺ opening for easy access to oxygen sensor SWR2
®
• Flank Drive wrenching system for greater applied torque
with less effort ELECTRONICS
• Ball detent in square drive for secure retention
• Industrial finish
SWR4A Oxygen Sensor Wrench
• Used on oxygen sensors with a 7/8ʺ (22 mm) hex
• Bent handle design with flex head offers extra clearance
for removal and installation of shielded oxygen sensors and SWR4A
air/fuel sensors
• Chrome finish for easy cleanup and protection against corrosion
• Depth of socket and wall diameter of socket is critical for
limited space inside heat shield
• Overall length: 10-3/4ʺl hex: 6 point 7/8ʺ; head diameter: 1-3/16ʺ
• Slot width: 1/2ʺ
SWR102 Oxygen Sensor Wrench Set
• SWR1 and SWR2 (2 pc) in a storage tray
SWR102

• Do not use “cheater bars” on handles
• Do not use chrome or industrial finish hand tools with impact drivers
• Do not expose gasoline or fuel to flames or other sources of ignition
