FUEL AND ENGINE SYSTEMS: FUEL SYSTEMS
ELECTRONICS

Injector Harness Testers
®
FID8838A Injector Harness Tester Set (Blue-Point ) FID8838A1 Injector Harness
• Each tester plugs into the solenoid harness to identify Tester (Blue-Point )
®
electrical or fuel system malfunctions • Used on GM Multec 2
®
®
• Includes (8) testers and an injector harness extension injectors used in 1999
• Includes a storage case and later 2.4 L 4-cylinder
®
FID8320 Injector Harness Tester (Blue-Point ) engines in Oldsmobile
®
®
• Used on GM TBI models 100, 200, 220, 300, 400 and Intrigue and Cutlass;
500 used on various cars and trucks Chevrolet Cavalier and
®
®
®
FID8329 Injector Harness Tester (Blue-Point ) Malibu ; and Pontiac
®
®
®
• Used on Bosch PFI injectors used on various GM , Ford Sunfire vehicles
®
®
®
and Chrysler vehicles with PFI FID8838A2 Injector FID8838A
FID8339 Injector Harness Tester (Blue-Point ) Harness Tester (Blue-Point )
®
®
®
®
®
• Used on GM Multec 1 injectors and the “bottom feed” • For use on Bosch 2 injectors used on 2000–later
®
®
injectors used on 2.2 L 4-cylinder “J” and “L” cars from Cadillac 4.6 L V8 and Oldsmobile 4.0 L V8 engines
1989–1993 FID8838A3 Injector Harness Extension (Blue-Point )
®
®
FID8340 Injector Harness Tester (Blue-Point ) • Injector harness extension line for all FID Series Injector
®
• Used on GM SCPI truck engines 4.3 L V6, 5.0 L V8 and Harness Testers
5.7 L V8 (1996–later), plus 4.8 L V8, 5.3 L V8, and 6.0 L V8 • Used when the injector is in a lower position in the
(1999–later) manifold or cylinder head
®
FID9210 Injector Harness Tester (Blue-Point )
• Designed for Geo TBI systems (1992–later)
&
FDT501 FDT502
FDT60
TESTING Fuel Line Disconnect Tools FDT602 FDT601 Flat Cummins Fuel Line Disconnect Tool
FDT50
FDT701
FDT601
FDT70
• Designed to service special quick-connect couplings found on fuel feed and return lines located at the engine
FDT50 Fuel Line Disconnect Set
®
• One bent tool and one straight tool provide versatility
• Designed to release the fuel line connectors on the
Cummins ISB and ISX engine family
when servicing VOSS-Type 3/8ʺ fuel line connectors
®
• Tools are .100 thick, allowing for increased access
• Works on low-pressure lines around the engine and chassis
• Spreader dimension is .806ʺ
• Measures .250 in thickness
FDT501 Cummins Flat Thin Disconnect Tool
®
• Designed to release the fuel line connectors on the
FDT602 Formed Cummins Fuel Line Disconnect Tool
®
• Designed to release the fuel line connectors on the
Cummins ISB, ISC, ISL, QSC8.3 and QSL9 engine family
®
• Tools work on the low-pressure lines of the
Cummins ISB and ISX engine family
®
• Works on low-pressure lines around the engine and chassis
Cummins engines • Compressing dimension .918ʺ
®
• Tools are .100 thick allowing for increased access • Measures .250 in thickness
• Spreader dimension is .806ʺ • Compressing dimension .918ʺ
®
FDT502 Cummins Thin Formed Disconnect Tool FDT70 Fuel Line Disconnect Set
• Designed to release the fuel line connectors on the • Tools are designed to release the VOSS-type 1/2ʺ fuel line
®
Cummins ISB, ISC, ISL, QSC8.3 and QSL9 engine family connectors on the Cummins ISB, ISC, ISL, QSC 8.3, and
®
• Tools work on the low-pressure lines of the QSL9 engine family
®
Cummins engines • Works on low-pressure lines around the engine and chassis
• Tools are .100 thick allowing for increased access • Measures .100 in thickness and includes one bent tool
• Spreader dimension is .806ʺ and one straight tool for versatility when servicing
®
FDT60 Fuel Line Disconnect Set Cummins engines
• Tools are designed to release the fuel line connectors on • Spreader dimension 1.115ʺ
®
®
the Cummins ISB and ISX engine family FDT701 Flat Cummins Fuel Line Disconnect Tool
• Works on low-pressure lines around the engine and chassis • Tools are designed to release the VOSS-type 1/2ʺ fuel line
®
• Measures .250 in thickness and includes one bent tool connectors on the Cummins ISB, ISC, ISL, QSC 8.3 and
and one straight tool for versatility when servicing QSL9 engine family
Cummins engines • Works on low-pressure lines around the engine and chassis
®
• Compressing dimension is .918ʺ • Measures .100 in thickness and includes one bent tool
and one straight tool for versatility when servicing
®
Cummins engines
• Spreader dimension 1.115ʺ
