FUEL AND ENGINE SYSTEMS: CARBURETOR

S6138E
S6137E
2006IT TESTING

S6139
TM64

TM65

TM83A TM84 TM85
TM615 &

TAM3E
Carburetor Adjustment Tools
2006IT Carburetor Adjusting Set TM83A Recessed Blade Carburetor Screwdriver
• Includes S6137E, S6138E, S6139, TM64, TM83A and TM85 • Used with TM64 or TM65 and other 1/4ʺ square
S6137E Idle Adjusting Hex Head Driver drive handles
®
• For 1978–later Chrysler vehicles • Blades are recessed in the outer socket wall to
• 3/32ʺ hex driver is 1-9/16ʺ long self-center
• 7/16ʺ O.D. • 1/4ʺ drive, 3/8 x 1/32ʺ blade
• 1/4ʺ drive industrial finish bit; nickel-chrome finish socket • Nickel-chrome finish
S6138E Idle Adjusting Driver TM84 Recessed Blade Carburetor Screwdriver
®
• For Ford feedback carburetors • Use with TM64 or TM65 and other 1/4ʺ square
• Bit has a 3/16 x 1/32ʺ flat tip, 2ʺ long drive handles
• 7/16ʺ O.D., 1/4ʺ drive • Blades are recessed in the outer socket wall to
• Industrial finish bit; nickel-chrome finish socket self-center ELECTRONICS
S6139 Double D Carburetor Adjusting Socket • 1/4ʺ drive, 7/16 x 1/32ʺ blade
• For 1978–later GM idle adjusting screw • Nickel-chrome finish
®
• 3.5 mm across flats, 13/16ʺ long TM85 Recessed Blade Carburetor Screwdriver
• 1/4ʺ drive, O.D. drive end is 7/16ʺ • Used with TM64 or TM65 and other 1/4ʺ square
• Nickel-chrome finish drive handles
TM64 Rigid Adjusting Tool • Blades are recessed in the outer socket wall to
• Features a rigid elbow bend rather than flexible self-center
• Used with carburetor drivers for making carburetor • 1/4ʺ drive, 9/32 x 1/32ʺ blade for adjusting
and point adjustments late-model Quadrajet carburetors
• Rigid shaft • Nickel-chrome finish
• Overall length is 18-1/4, 1/4ʺ drive TAM3E Metric Hex Head Driver
TM65 Flexible Adjusting Tool • Used to make carbon monoxide adjustments on
®
®
• Flexible shaft end for working in restricted areas 1976 Dasher, 1974–1976 Audi and Volvo , and 1975
®
®
• Ideal for working in tight spaces when servicing and 1976 Fiat and Saab vehicles
window-type distributors • 3 mm bit size, 1/4ʺ drive
• Knob markings allow for counting turns • 6-7/8ʺ long
• Overall length is 19-3/4, 1/4ʺ drive • Nickel-chrome finish
TM615 1/4ʺ Drive Standard Handle Extra-Long
Flexible Driver
• Designed for carburetor work; this driver can also access
recessed distributors
• 1/4ʺ drive at the end of a tough but flexible spring
steel shank
• Ideal to access hard-to-reach adjusting screws
• Intended for low-torque applications

• Do not use “cheater bars” on handles 649
• Do not use chrome or industrial finish hand tools with impact drivers
• ‡ These products can expose you to chemicals which are known to the state of California to cause
cancer and reproductive harm. See pages 906-907 for details.
• Read safety precautions on pages W1 to W4
