FUEL AND ENGINE SYSTEMS: COMPRESSION GAUGE SETS AND ADAPTORS
ELECTRONICS

EEPV5G10L EEPV5G12L EEPV5G14L EEPV5G16T EEPV5G18S

EEPV5G10S EEPV5G12T EEPV5G14S EEPV6G16L

EEPV6G12L EEPV6G14L

EEPV6G3PK
EEPV6G14S
Compression Gauge Adaptors
• Detects piston ring, intake/exhaust valve, head gasket or other engine issues
• 10-1/4ʺ overall length unless otherwise noted
• For EEVPV6 adaptors: Simply connect the hose coupler and gauge of the customer’s existing EEPV500 or EEPV600
(EEPV500 and EEPV600 sold separately)
EEPV5G10L ‡ Compression EEPV5G14L ‡ Compression EEPV5G18S ‡ Compression
Gauge Adaptor
Gauge Adaptor
Gauge Adaptor
& • Long reach (M10 x 1.0 pitch) • Long reach (M14 x 1.25 pitch) • Standard reach (M18 x 1.5 pitch)
• Thread length: .44ʺ
• Thread length .70ʺ
• Thread length: .73ʺ
EEPV5G10S ‡ Compression EEPV5G14S ‡ Compression EEPV6G3PK ‡ 3 pc Chrome
Gauge Adaptor
Compression Adaptor Set
Gauge Adaptor
TESTING Gauge Adaptor ® ® Chrome Adaptor ® • Simplifies testing of compression on
• Standard reach (M14 x 1.25 pitch)
• Set includes EEPV6G12L, EEPV6G14L
• Standard reach (M10 x 1.0 pitch)
and EEPV6G14S (3 pc)
• Thread length: .36ʺ
• Thread length: .43ʺ
• For use with EEPV500 and EEPV503
EEPV5G12L ‡ Compression
EEPV6G14L ‡ Long Reach
compression gauge sets
• Long reach (M12 x 1.25 pitch)
• M14 x 1.25 pitch
engines with deep spark plug wells
• Thread length: .68ʺ
EEPV6G14S ‡ Standard Reach
• Knurled end allows hand tightening
EEPV5G12T ‡ Compression
Chrome Adaptor
to aid against over-torquing and
• M14 x 1.25 pitch
Gauge Adaptor
cross-threading
®
• Ford Triton engines 2008 and later
®
EEPV5G16T ‡ Compression
EEPV6G1822 M18 X 1.5 Thread
• Mercedes-Benz (most V6 and
Gauge Adaptor
Compression Adaptor
some V8 models newer than 2006),
• Long reach (M16 x 1.5 pitch) for Ford
• For use with EEPV6-300G gauge and
®
Nissan (2.5 L 2008 and later) and
5.4 L Triton engines
®
EEPV600H (sold separately)
®
Toyota Scion (1.8 L 2008 and
later) vehicles
EEPV6G16L ‡ Long Reach
• 22” overall length for long reach
• 18ʺ length
applications
Chrome Adaptor
• Thread length: .71ʺ
• M16 x 1.25 pitch
EEPV6G12L ‡ Long Reach
Chrome Adaptor • 18ʺ length • M18 x 1.50 pitch
• M12 x 1.25 pitch EEPV6G1822
Cone-Type Compression Gauge
MT27D Cone-Type Compression Gauge
• Range from 0–300 PSI and 0–2,100 kPa
• Cone seal is held firmly over plug hole, unit does not thread in
• Ideal for small gasoline engines, motorcycles, ATVs and snowmobiles
MT27D
