ELECTRONICS TACHOMETERS

Tachometers
EEDMTACH1A Digital Contact/Non-Contact
Laser Tachometer
• Ideal for use on fan or serpentine belts, industrial
equipment, race cars, marine, motor sports, ATV,
big rig engines and more
• Measures RPM on vehicle components and
industrial equipment
• Obtains RPM readings up to 25 feet away from its target
• No-contact laser mode works great in tight areas and
keeps the user away from moving parts
• Unique pistol grip design fits comfortably in the hand
• Line-of-sight aiming design provides easy-to-read results
on the LCD color display—easily read in low or bright
sunlight conditions
• Memory recall brings back the last measurement on the
EEDMTACH1A display before powering off
• Uses standard 9 V batteries
• Up to 30,000 RPM non-contact
MTTACH1A1 24 pk Reflective 1/2ʺ Squares
• Reflective photo tape for the EEDMTACH1 Tachometer
EEDMRPM500 EEDMRPM500 Digital Tachometer (Gas Engines)
• Used to digitally read RPM on single cylinder, 2- or
4- stroke gas engines
• Choose between 2- or 4-stroke engines and 1- or 2-spark
ignition systems
• Unit provides min/max readings with eight storage
locations to save readings for future reference
& • 300–10,000 RPM range
• Powered by 9 V battery (included)
• Overall dimensions: 2-3/4 x 5-3/4 x 1ʺ
EEDMRPMD500 Diesel Engine Adaptor
TESTING • 300-6,000 RPM range ® ®
EEDMRPMD500
• Optional diesel engine adaptor for the EEDMRPM500
Digital Tachometer
• For use on diesel engines only

Diesel Pulse Adaptor (Blue-Point )
MT257B Diesel Pulse Adaptor (Blue-Point )
• Tests injector timing or engine RPM on diesel engines
equipped with 1/4ʺ or 6 mm external steel fuel
injector lines
• Enables use with inductive pick-up timing light to test
engine timing
• Not for use on diesels with common rail fuel systems

MT257B

SPECIALTY METERS AND SMALL TESTERS

Coil-On-Plug (COP) Ignition Probes
®
(Blue-Point )
YA76562 Ignition Quick Probe (Blue-Point )
®
• Quickly verifies the firing of a coil-on-plug (COP) ignition
coil and spark plug
• Eliminates the need for back probing coil wires and
YA76562
disassembly to test at the coil connector or spark plug
• Variable sensitivity (VS) thumbwheel for greater
diagnostic accuracy and expanded application coverage
630 • Super-bright KV and ARC indicator LEDs
