EXTRACTORS: EXTRACTOR TOOLS
TOOLS Combination Extractor Sets

EXD10 10 pc Right-Hand Extractor Set
• Includes (5) right-hand, mechanic’s-length cobalt drill bits
(19/64, 1/4, 5/32, 5/64 and 7/64ʺ) and (5) spiral flute screw
extractors (EX1, EX2, EX3, EX4, EX5) in a metal index
EXDL10 10 pc Left-Hand Extractor Set
• Includes (5) left-hand, mechanic’s-length cobalt drill bits
(19/64, 1/4, 5/32, 5/64 and 7/64ʺ) and (5) spiral flute screw
extractors (EX1, EX2, EX3, EX4, EX5) in a metal index
®
E1025 39 pc Extractor Set (Blue-Point )
• Extract broken screws from 1/4–1ʺ dia. and standard pipe
HAND • Includes a storage case ®
EXD10
sizes 1/8–1ʺ
EXDL10
• Includes (8) right-hand drill bits, (10) solid-type drill guides,
(1) sleeve spacer, (2) sleeve-type drill guides, (4) sleeve
bushings, (8) straight screw extractors and (6) pipe
plug extractors
E1020 19 pc Extractor Set (Blue-Point )
• Extract broken screws from 1/4–1/2ʺ diameter
• Includes (5) right-hand drill bits (1/8, 3/16, 1/4, 5/16 and
11/32ʺ), (9) solid-type drill guides (9/32–9/16ʺ diameter) and
(5) straight screw extractors plus hex collars (#1–5)
GENERAL
E1020 • Includes a storage case
E1025
Multispline Extractors
• Shoulder prevents the extractor from entering too deeply and
expanding the screw
REX25B 25 pc Multispline Extractor Set
• Includes (25) multispline extractors REX104A–REX128A
(1/8–7/8ʺ)
• Includes a REX25BMT storage case
REX10B 10 pc Multispline Extractor Set
• Includes REX104A–REX113A (1/8–13/32ʺ) (10 pc) in a
REX10BMT storage case
REX15B 15 pc Multispline Extractor Set
• Includes (15) multispline extractors 1/8–9/16ʺ in a
REX15BMT storage case
REX25B
Drill Size, Bolt Size, Pipe Size, Hex Size,
Stock No. Mark
inches inches inches inches
REX104A 1/8 1/4 — 1/2 A
REX105A 5/32 5/16 — 1/2 B
REX106A 3/16 3/8 — 1/2 C
REX107A 7/32 7/16 — 1/2 D
REX108A 1/4 1/2 1/8 1/2 E
REX109A 9/16 9/32 — 1/2 F
REX110A 5/16 5/8 — 1/2 G
REX111A 11/32 11/16 1/4 1/2 H
REX112A 3/8 3/4 — 1/2 I
REX113A 13/32 13/16 — 1/2 J
REX10B REX114A 7/16 7/8 — 5/8 K
REX115A 15/32 15/16 3/8 5/8 L
REX116A 1/2 1 — 5/8 M
REX117A 17/32 1-1/16 — 5/8 N
REX118A 9/16 1-1/8 — 3/4 O
REX119A 19/32 1-3/16 — 3/4 P
REX120A 5/8 1-1/4 1/2 3/4 Q
REX121A 21/32 1-5/16 — 7/8 R
REX122A 11/16 1-3/8 — 7/8 S
REX123A 23/32 1-7/16 — 7/8 T
REX124A 3/4 1-1/2 — 7/8 U
REX125A 25/32 1-9/16 3/4 1 V
REX126A 13/16 1-5/8 — 1 W
REX15B REX127A 27/32 1-11/16 — 1 X
448
REX128A 7/8 1-3/4 — 1 Y
Sets include REX15BMT plastic storage case.
