THREADING: TAPS AND DIE SETS
TOOLS T1412M T18150 TDM100 TMA34 34 pc Metric Tap Set

• 34 pc set features
popular metric taps from
3–18 mm sizes
• Precision ground flutes
ensure accurate threading
• High-carbon steel ensures
less breakage
socket drive into a tap driver
Metric Tap Set
Thread Size
Stock No. Thread Size Stock No. ATSL Thread Size TMA34 Stock No. • Tap adaptors turn any 3/8ʺ
HAND T4075M M6 x 1.00 T1012M M10 x 1.25 T1620M Adj. Tap Socket, 3–6 mm
M16 x 1.00
M3 x .50
M9 x 1.25
T912M
T305M
T1610M
M16 x 1.50
M3 x .60
M10 x 1.00
T306M
T1615M
T1010M
M16 x 2.00
M4 x .75
M18 x 1.50
M10 x 1.50
M4 x .70
T18150
T407M
T1015M
M18 x 1.50
M11 x 1.50
M5 x .80
T508M
T1815M
T1115M
M12 x 1.25
M5 x .90
M18 x 2.50
T509M
T1212M
T1825M
M12 x 1.50
—
T610M
TDM100
T1215M
M6.33 x 1
M12 x 1.75
T6310M
T1217M
ATSS
(3/8ʺ Drive)
T710M
M14 x 1.25
M8 x 1.00
T810M
T1412M
(3/8ʺ Drive)
M14 x 1.50
M8 x 1.25
T812M
T1415M
M14 x 2.00
M9 x 1.00
T910M M7 x 1.00 T14125 M14 x 1.25 ATSL Adj. Tap Socket, 6–12 mm
T1420M
GENERAL
GAM541 41 pc Metric Tap and Die GA541 41 pc SAE Tap and Die
®
Set (Blue-Point ) Set (Blue-Point )
®
• 41 pc set features 1ʺ single • 41 pc set features taps and
hex non-adjustable dies from dies from #4 to 1/2ʺ in both
3–12 mm, a 1/8ʺ-28 BSP die, NF and NC threads, a pipe
plus taps in the same sizes thread tap and die, plus
• Also includes a die stock, (2) (2) die stocks and (3) tap
T-handle tap wrenches, a thread wrenches, a screw pitch
pitch gauge, a drill/tap chart, gauge, screwdriver and a
GAM541
screwdriver and storage case storage case
GA541
SAE Left-Hand Tap and Die Sets
Stock No. Description Thread Size Stock No. Description Thread Size
DLH010 Left Hand Die 1/4-20 NC TLH104 Left Hand Tap 1/2-13 NC Plug
DLH011 Left Hand Die 5/16-18 NC TLH105 Left Hand Tap 1/4-28 NF Plug
DLH012 Left Hand Die 3/8-16 NC TLH106 Left Hand Tap 5/16-24 NF Plug
DLH013 Left Hand Die 7/16-14 NC TLH107 Left Hand Tap 3/8-24 NF Plug
DLH014 Left Hand Die 1/2-13 NC TLH108 Left Hand Tap 7/16-20 NF Plug
DLH015 Left Hand Die 1/4-28 NF TLH109 Left Hand Tap 1/2-20 NF Plug
DLH016 Left Hand Die 5/16-24 NF TLH111 Left Hand Tap 4-40 NC Plug
DLH017 Left Hand Die 3/8-24 NF TLH112 Left Hand Tap 6-32 NC Plug
DLH018 Left Hand Die 7/16-20 NF TLH113 Left Hand Tap 8-32 NC Plug
DLH019 Left Hand Die 1/2-20 NF TLH114 Left Hand Tap 10-24 NC Plug
DLH021 Left Hand Die 4-40 NC TLH115 Left Hand Tap 10-32 NF Plug
DLH022 Left Hand Die 6-32 NC TLH116 Left Hand Tap 12-24 NC Plug
DLH023 Left Hand Die 8-32 NC TDALTSB T-Bar for Adj. Tap Socket —
DLH024 Left Hand Die 10-24 NC TDALDS1 Die-Stock 1 Double Hex Dies —
DLH025 Left Hand Die 10-32 NF TDALDSS Die Spacer —
DLH026 Left Hand Die 12-24 NC TDALTS1 Adjustable Tap Socket 0–1/4ʺ
TLH100 Left Hand Tap 1/4-20 NC Plug TDALTS2 Adjustable Tap Socket 1/4–1/2ʺ
TLH101 Left Hand Tap 5/16-18 NC Plug TD1040 SAE Thread, Pitch Gauge —
TLH102 Left Hand Tap 3/8-16 NC Plug TDM1040 Metric Thread Pitch Gauge Metric
TLH103 Left Hand Tap 7/16-14 NC Plug
TDLH139 Left-Hand Thread Tap and Die Set
• Built exclusively for left-hand applications
• Set comprises the most popular SAE left-hand taps and dies: #4–1/2ʺ sizes
• High-quality handle with (2) adjustable tap sockets (0–1/4ʺ and 1/4–1/2ʺ)
provides secure, precise hold during tapping applications
