THREADING: SELF-ALIGNING TAPS AND DIES

Tap and Die Drive Tool System
TDM100 Metric Thread Pitch Gauge
TDRSET 7 pc Tap and Die Drive Tool Set
• Set includes (1) die stock, (2) adjustable tap sockets,
(1) die spacer, (1) T-bar handle, (1) SAE thread pitch gauge TDM100
and (1) metric thread pitch gauge
TDALDS1 1ʺ Double Hex Die Stock GENERAL
• Features a twist die lock, so no set screws are needed
• Simply twist to insert or remove the die
• Ergonomic handles for comfort and control when threading
• Fits 1ʺ double hex dies
TDALTS2 1/4–1/2ʺ Adjustable Tap Socket
• For 1/4ʺ and 1/2ʺ (M7 x 1.00 and M12 x 1.75) taps
• Versatile base can be driven with die stock, 3/8ʺ ratchet
or T-bar handle
TDALTSB T-Bar Handle (For TDALTS)
• For TDALTS1 and TDALTS2 Adjustable Tap Sockets
TD1040 SAE Thread Pitch Gauge
• Measures US or sharp V threads TDRSET
• Includes 18 plated blades for the following thread sizes: 8, 9,
10, 11, 11-1/2, 12, 13, 14, 16, 18, 20, 24, 27, 28, 32, 36, 40 and 44
threads per inch HAND

TD1040

SAE/Metric Tap Set
TAMA141 SAE/Metric Plug Tap Set
• Built for those who frequently tap and need a
comprehensive set of taps TOOLS
• Wide array of taps in most popular SAE and
metric sizes
• High-quality handle with two adjustable
tap sockets (0-1/4ʺ and 1/4–1/2ʺ)
provides secure, precise hold during Set TAMA141 Set TAMA141
tapping applications Contains: TAMA141 Contains:
Stock No. Description Thread Size Stock No. Description Thread Size
T100 1ʺ Double Hex Adjustable Tap 1/4ʺ-20 NC • T1212M Right-Hand Plug Tap M12 x 1.25 •
T101 1ʺ Double Hex Adjustable Tap 5/16ʺ-18 NC • T1217M Metric Double Hex Tap M12 x 1.75 •
T1012M Metric Double Hex Tap M10 x 1.25 • T305M Metric Double Hex Tap M3 x .50 •
T1015M Metric Double Hex Tap M10 x 1.50 • T4075M Metric Double Hex Tap M4 x .75 •
T102 1ʺ Double Hex Adjustable Tap 3/8ʺ-16 NC • T407M Metric Double Hex Tap M4 x .70 •
T103 1ʺ Double Hex Adjustable Tap 7/16ʺ-14 NC • T508M Metric Double Hex Tap M5 x .80 •
T104 1ʺ Double Hex Adjustable Tap 1/2ʺ-13 NC • T509M Metric Double Hex Tap M5 x .90 •
T105 National Fine Thread Tap 1/4ʺ-28 NF • T610M Metric Double Hex Tap M6 x 1.00 •
T106 National Fine Thread Tap 5/16ʺ-24 NF • T710M Metric Double Hex Tap M7 x 1.00 •
T107 National Fine Thread Tap 3/8ʺ-24 NF • T810M Metric Double Hex Tap M8 x 1.00 •
T108 National Fine Thread Tap 7/16ʺ-20 NF • T812M Metric Double Hex Tap M8 x 1.25 •
T109 National Fine Thread Tap 1/2ʺ-20 NF • T910M Metric Tap M9 x 1.00 •
T110 Pipe Thread Tap 1/8ʺ-27 NPT • T912M Metric Double Hex Tap M9 x 1.25 •
T110M Metric Double Hex Tap 1/8ʺ-28 BSP • TDM100 Metric Thread Pitch Gauge — •
T1115M Metric Double Hex Tap M11 x 1.50 • TD1040 SAE Thread, Pitch Gauge — •
T111A 5/8ʺ Double Hex Adjustable Tap 4-40 • TDALDS1 Die-Stock 1 Double Hex Dies — •
T112 5/8ʺ Double Hex Adjustable Tap 6-32 • TDALDSS Die Spacer — •
T113 5/8ʺ Double Hex Adjustable Tap 8-32 • TDALTS1 Adjustable Tap Socket 0–1/4ʺ •
T114 5/8ʺ Double Hex Adjustable Tap 10-24 • TDALTS2 Adjustable Tap Socket 1/4–1/2ʺ •
T115 5/8ʺ Double Hex Adjustable Tap 10-32 • TDALTSB T-Bar for Adj. Tap Socket — •
T116 5/8ʺ Double Hex Adjustable Tap 12-24 •
