THREAD RESTORING: FILES AND THREAD CHASERS
TOOLS T14125 Metric Spark Plug Hole Taps M10 x 1.00

Stock No.
Size
T10100
M12 x 1.25
T12125
M14 x 1.25
T14125
M18 x 1.50
T18150
7/8ʺ-18 NF
T2818
HAND TDM101 Thread Gauge

TDM101 Metric Bolt and Thread Gauge
• Bolt diameter range of 2.3–24 mm (with inch/decimal equivalents)
• Thread gauge sizes: .35–3 mm

Tap and Die Accessories
GENERAL
TD1040 SAE Thread Pitch Gauge
• Measures US or sharp V threads
• Includes 18 plated blades for the following thread sizes: 8, 9, 10, 11,
11-1/2, 12, 13, 14, 16, 18, 20, 24, 27, 28, 32, 36, 40 and 44 threads
per inch
TD1040

Thread Restoring Files
TFTFM932A 3 pc Thread Restoration File Set (Blue-Point )
®
• Includes (3) commonly needed files
• Files feature a black industrial finish and comfortable vinyl handles
• Files service a range of 9–32 threads per inch and
0.75–3 mm pitches
• Includes a TFTFM932-1 Vinyl Kit Bag for storage
TF1124B ‡ Thread Restorer File (Blue-Point )
®
• 11, 12, 13, 14, 16, 18, 20 and 24 threads per inch
TF1127B ‡ Thread Restorer File (Blue-Point )
®
• 9, 10, 12, 16, 20, 27, 28 and 32 threads per inch
®
TFM7530B ‡ Thread Restorer File (Blue-Point )
• For any diameter right- or left-hand threads
• Removable vinyl handle
• Eight pitches: .75, 1, 1.25, 1.5, 1.75, 2, 2.5 and 3 mm
TFTFM932A

TF1124B

442
• ‡ These products can expose you to chemicals which are known to the state of California to cause
cancer and reproductive harm. See pages 906-907 for details.
