THREADING: TAP AND DIE SETS

TD9902B TD2425 TDTDM500A TDM99117 GENERAL

Set TD9902B TD9902 TD2425 TDM99117 TDM117A
TDM99117B TDM117A
Contains:
TDTDM500A
TDM99117B
SAE/ SAE/
Tap Stock Die Stock SAE SAE SAE Metric Metric
Thread Size Die Type Metric Metric
No. No. Set Set Set Set Set
Set Set
Metric M3 x .50 T305M D305M 5/8ʺ Double Hex Adjustable • • •
Threads M3 x .60 T306M D306M 5/8ʺ Double Hex Adjustable HAND
M4 x .70 T407M D407MA 5/8ʺ Double Hex Adjustable • • •
M4 x .75 T4075M D4075M 5/8ʺ Double Hex Adjustable • • •
M5 x .80 T508M D508MA 5/8ʺ Double Hex Adjustable • • •
M5 x .90 T509M D509M 5/8ʺ Double Hex Adjustable • • •
M6 x 1.00 T610M D610MA 5/8ʺ Double Hex Adjustable • • •
M7 x 1.00 T710M D710M 1ʺ Double Hex Adjustable • • •
M8 x 1.00 T810M D810M 1ʺ Double Hex Adjustable • • •
M8 x 1.25 T812M D812M 1ʺ Double Hex Adjustable • • •
M9 x 1.00 T910M D910M 1ʺ Double Hex Adjustable • • •
M9 x 1.25 T912M D912M 1ʺ Double Hex Adjustable • • •
M10 x 1.25 T1012M D1012M 1ʺ Double Hex Adjustable • • •
M10 x 1.5 T1015M D1015M 1ʺ Double Hex Adjustable • • •
M11 x 1.5 T1115M D1115M 1ʺ Double Hex Adjustable • • • TOOLS
M12 x 1.5 T1215M D1215M 1ʺ Double Hex Adjustable • • •
M12 x 1.75 T1217M D1217M 1ʺ Double Hex Adjustable • • •
M14 x 1.25 T1412M DR1412M 1-1/2ʺ Round Adjustable • •
M14 x 1.5 T1415M DR1415M 1-1/2ʺ Round Adjustable • •
M14 x 2.0 T1420M DR1420M 1-1/2ʺ Round Adjustable • •
M16 x 1.5 T1615M DR1615M 1-1/2ʺ Round Adjustable • •
M16 x 2.0 T1620M DR1620M 1-1/2ʺ Round Adjustable • •
M18 x 1.5 T1815M DR1815M 1-1/2ʺ Round Adjustable • •
M18 x 2.5 T1825M DR1825M 1-1/2ʺ Round Adjustable • •
M20 x 2.5 T2025M DR2025M 2ʺ Round Adjustable • •
M22 x 1.5 T2215M DR2215M 2ʺ Round Adjustable • •
M24 x 2.0 T2420M DR2420M 2ʺ Round Adjustable • •
M24 x 3.0 T2430M DR2430M 2ʺ Round Adjustable • •
1/8ʺ-28 BSP T110M D020M 1ʺ Double Hex Non-Adjustable • • •
Accessories Thread Size Stock No. Die Type
TD3A Die Stock TD3A For 5/8ʺ Double Hex Dies • • • • • •
TD10A Die Stock TD10A Self-Centering for 1ʺ Double Hex Dies • • • • • •
Self-Centering for
TD35 Die Stock TD35 • • • •
1-1/2ʺ Dia. Round Dies
TD40 Die Stock TD40 Self-Centering for 2ʺ Dia. Round Dies • • • •
TD4 Tap Wrench TD4 4 Jaw, for 0–1/4ʺ Taps • • • • • •
4 Jaw for 1/4–1/2ʺ
TF50 Tap Wrench TD50 • • • • • •
(M7 x 1.00–M12 x 1.75) Taps
TD88A Tap Wrench TD88A Clamp Type, for 0–1/2ʺ • • • • • •
(M3 x 0.50–M12 x 1.75) Taps
Clamp Type for 0–1ʺ
TD98A Tap Wrench TD98A (M7 x 1.00–M24 x 3.0) Taps • • • •
SAE Thread, Pitch Gauge TD1040 SAE • • •
Metric Thread, Pitch Gauge TDM100 Metric • • •
TDS1 Screwdriver TDS1 For Adjusting Dies • • • • • •
