THREADING: TAP AND DIE SETS
TOOLS TDTDM117A 117 pc Master Tap and Die Set TDTDM117A TD9902B TD2425 TDTDM500A
SAE/Metric Combination Set
• Includes all components of the TDTDM500A SAE/Metric set
plus 41 pc 118° high-speed steel drill bit set in SAE, metric,
wire gauge and letter sizes, and (5) spiral screw extractors
• Each drill bit matches to corresponding tap size for correct fit
• Set offers a complete assortment of high-carbon steel taps
and dies in SAE and metric sizes
• Tap/drill charts and tool diagrams included
Set
• Set packaged in a storage case
Contains:
US/Metric
National Fine Threads
Die Type
Thread Size
US Set US Set US Set US Set
(adjustable dies) 5/16ʺ-24 NF Tap Stock Die Stock No. 1ʺ Double Hex Adjustable TD9902B TD9902 • • • TD2425 • • • TDP6 TDTDM500A • • •
No.
Set
D015
1/4ʺ-28 NF
T105
HAND 7/16ʺ-20 NF T108 — D018 1ʺ Double Hex Adjustable • • • • • • • • • • • • •
D016
T106
1ʺ Double Hex Adjustable
D017
T107
3/8ʺ-24 NF
1ʺ Double Hex Adjustable
T109
1/2ʺ-20 NF
1ʺ Double Hex Adjustable
D019
1/2ʺ-20 NF
1-1/2ʺ Round Adjustable
DR019
1-1/2ʺ Round Adjustable
T125
DR035
9/16ʺ-18 NF
5/8ʺ-18 NF
T126
1-1/2ʺ Round Adjustable
DR036
3/4ʺ-16 NF
1-1/2ʺ Round Adjustable
DR037
T127
2ʺ Round Adjustable
DR043
T129
2ʺ Round Adjustable
1ʺ-14 NF
National
T105
GA541-1428
1/4ʺ-28 NF
Fine Threads 7/8ʺ-14 NF T128 DR042 1ʺ Single Hex Non-Adjustable • • • •
T106
(non-adjustable dies) 5/16ʺ-24 NF — —
GENERAL
3/8ʺ-24 NF T107 GA541-3824 1ʺ Single Hex Non-Adjustable
7/16ʺ-20 NF T108 — —
1/2ʺ-20 NF T109 — —
National 1/4ʺ-20 NC T100 D010 1ʺ Double Hex Adjustable • • •
Coarse Threads 5/16ʺ-18 NC T101 D011 1ʺ Double Hex Adjustable
(adjustable dies) • • •
3/8ʺ-16 NC T102 D012 1ʺ Double Hex Adjustable • • •
7/16ʺ-14 NC T103 D013 1ʺ Double Hex Adjustable • • •
1/2ʺ-13 NC T104 D014 1ʺ Double Hex Adjustable • • •
1/2ʺ-1 NC — DR014 1-1/2ʺ Round Adjustable •
9/16ʺ-12 NC T120 DR030 1-1/2ʺ Round Adjustable • •
5/8ʺ-11 T121 DR031 1-1/2ʺ Round Adjustable • •
3/4ʺ-10 NC T122 DR032 1-1/2ʺ Round Adjustable • •
7/8ʺ-9 NC T123 DR040 2ʺ Round Adjustable • •
1ʺ-8 NC T124 DR041 2ʺ Round Adjustable • •
National 1/4ʺ-20 NC T100 GA541-1420 1ʺ Single Hex Non-Adjustable
Coarse Threads
(non-adjustable dies) 5/16ʺ-18 NC T101 GA541-51618 1ʺ Single Hex Non-Adjustable
3/8ʺ-16 NC T102 GA541-3816 1ʺ Single Hex Non-Adjustable
7/16ʺ-14 NC T103 GA541-71614 1ʺ Single Hex Non-Adjustable
1/2ʺ-13 NC T104 GA541-1213 1ʺ Single Hex Non-Adjustable
Machine 4-40 T111A D021A 5/8ʺ Double Hex Adjustable • • •
Screw Threads 6-32 T112 D022 5/8ʺ Double Hex Adjustable
(adjustable dies) • • •
8-32 T113 D023 5/8ʺ Double Hex Adjustable • • •
10-24 T114 D024 5/8ʺ Double Hex Adjustable • • •
10-32 T115 D025 5/8ʺ Double Hex Adjustable • • •
12-24 T116 D026 5/8ʺ Double Hex Adjustable • • •
Machine 4-40 T111A — —
Screw Threads 6-32 T112 GA541-632 5/8ʺ Single Hex Non-Adjustable
(non-adjustable dies)
8-32 T113 — —
10-24 T114 GA541-1024 5/8ʺ Single Hex Non-Adjustable
10-32 T115 GA541-1032 5/8ʺ Single Hex Non-Adjustable
12-24 T116 GA541-1224 5/8ʺ Single Hex Non-Adjustable
Pipe Threads 1/8ʺ-27 NPT T110 — — • • •
(adjustable dies)
1/8ʺ-27 NPT — D020 1ʺ Double Hex Non-Adjustable • • •
1/4ʺ-18 NPT T130 — — • • •
1/4ʺ-18 NPT — DR033 1-1/2ʺ Round Adjustable • •
3/8ʺ– 18 NPT T131 — — •
1/2ʺ-14 NPT T132 — — •
3/4ʺ-14 NPT T133 — — •
1ʺ-11-1/2ʺ NPT T134 — — •
Pipe Threads 1/8ʺ-27 NPT T110 GA541-1827 1ʺ Double Hex Non-Adjustable
(non-adjustable dies)
®
TDP6-1 Wood Box (for TDP6) (Blue-Point )
440 TDTDM500AMT Plastic Box (for TDTDM500A)
