FLANK DRIVE SPARK PLUG SOCKETS

S9716KR S9706KRFUA S9704KR S9714MKR
Retention
• Patented tapered hex design securely • Side through hole for secure • Nickel-chrome plating helps protect
retains spark plug in socket without extension retention for coil on against corrosion and makes it easy GENERAL
rubber insert or magnet plug applications to wipe clean
• Patented diamond wedge design with • Snap-on sockets using the Flank • Spark plug socket is cold-formed
®
six wedges equally aligns the plug Drive wrenching system grip the for extended tool life
®
in the center to avoid damage to the fastener on the flanks/flats which • Knurled surface for finger
porcelain (US Patent #6,626,067) deliver 15–25% more turning power tightening/removal
• Spark plug is easily disengaged by • Manufactured from the highest • External hex on standard models
applying gentle side pressure quality proprietary steel, providing for restricted-access applications
• Spark plug extends through the optimum strength and durability
socket for access in tight quarters
A B C
9/16ʺ S9716KR 5/8 25/32 2-3/8
5/8ʺ S9706KRFUA N/A 27/32 3-3/4
5/8ʺ S9706KRA 11/16 27/32 2-7/8
13/16ʺ S9704KR 7/8 1-1/16 2-27/32
14 mm S9714MKR 16 mm 19.6 mm 60.3 mm HAND
ANSI B107.34M
®
®
®
S9704KR 3/8ʺ Drive 6-Point SAE 13/16ʺ Flank Drive S9706KRFUA 3/8ʺ Drive 6-Point SAE 5/8ʺ Flank Drive
Standard Retention Spark Plug Socket Universal Retention Spark Plug Socket
• Applications include the removal and installation of • Applications include 4.7 L engines used on Jeep
®
13/16ʺ spark plugs Commander and Grand Cherokee , RAM , Durango and
®
®
®
®
®
®
S9706KRA 3/8ʺ Drive 6-Point SAE 5/8ʺ Flank Drive Dakota plus Chrysler Aspen vehicles, plus general
®
Standard Retention Spark Plug Socket applications on autos, light trucks, motorcycles and
®
• Applications include 4.7 L engines used on Jeep power equipment
®
Commander and Grand Cherokee , RAM , Durango and S9714MKR 3/8ʺ Drive 6-Point Metric 14 mm Flank Drive
®
®
®
®
®
Dakota plus Chrysler Aspen vehicles, plus general Retention Spark Plug Socket
®
®
applications on autos, light trucks, motorcycles and • Applications include 14 mm spark plugs used in Nissan
®
®
power equipment 1.8 L Versa and 2.0 L Sentra , Mercedes and
®
BMW vehicles TOOLS
®
Special Application
• Spark plug extends through the socket for access in tight quarters
• Patented tapered hex design securely retains the spark plug in the socket S9723
without a rubber insert or magnet
• Patented diamond wedge design with six wedges equally aligns the spark
plug in the center to avoid damage to the porcelain
• Spark plug is easily disengaged from the socket by applying gentle side
pressure to break the contact S9704RHS
• 5/8ʺ offset spark plug socket for limited-access situations
• Side through-hole for secure extension retention
• Snap-on sockets using the Flank Drive wrenching system grip the fastener on the
®
®
flanks/flats, delivering 15–25% more turning power
• Manufactured from the highest quality proprietary steel, providing optimum strength
and durability S9724RHS
• Nickel-chrome plating helps protect against corrosion and makes it easy to wipe clean
• Spark plug socket is cold formed for extended tool life
S9723 3/8ʺ Drive 12-Point SAE 5/8ʺ Flank Drive Offset OGS1528 1/2ʺ Drive 6-Point SAE 7/8ʺ
®
Spark Plug Socket Spark Plug Socket
• Knurled surface for finger tightening and removal • Manufactured from special alloy steel
S9704RHS 3/8ʺ Drive 6-Point SAE 13/16ʺ Flank Drive • Precision machined and heat treated for optimum
®
Low-Profile Spark Plug Socket strength and durability
• Low-profile socket easily reaches spark plugs without • Retaining ring holds the spark plug in the socket to aid
interference from custom exhausts or chassis in removal and installation
• Knurled surface for finger tightening and removal • Used for removing and installing spark plugs on large
Waukesha Engine Generators
®
®
S9724RHS 3/8ʺ Drive 6-Point SAE 5/8ʺ Flank Drive
Low-Profile Spark Plug Socket
• Low-profile socket easily reaches spark plugs without
interference from custom exhausts or chassis
• Do not use chrome or industrial finish hand tools with impact drivers 437
