TUBING, CUTTERS, FLARING AND BENDING
TOOLS TBS100 TBS100 Tubing Bender (Blue-Point ) TBS300 Tubing Bender (Blue-Point )
Bending Tools
®
®
• Bends tubing up to 1/4ʺ O.D.
• Easily bend 1/4, 5/16 and 3/8ʺ O.D. soft
copper or aluminum tubing up to 180°
• Bends copper, brass, bundy weld,
non-coated brake lines and more
• Degrees, in 15° increments, shown on tool
• Comfort grip handle
for accurate bends
• Pull lever to easily disengage the tool
• 7ʺ long
after bending
TBS200A Multipurpose Tubing Bender
TBS200A
(Blue-Point )
®
control, even with greasy hands
• Makes left, right or offset bends up to
• Offset handles provide hand clearance
a 90° angle
when making 180° bends
• Degrees shown on tool for accurate bends • Cushioned handles provide comfort and
• Handles 3/16, 1/4, 5/16 and 3/8ʺ (4, 6 and • Lightweight die-cast aluminum
HAND TUBING: FLARING AND BENDING ® • Clamp and set screws put pressure directly
construction
8 mm) O.D. aluminum, copper and stainless
• 10-1/2ʺ long
TBS300
steel tubing
• Aluminum unit is 8-1/4ʺ long when opened
Flaring Tool Sets (Blue-Point )
TF528D Tube Cutting and Double Flaring
®
Set (Blue-Point )
of the tube slipping from the clamp;
• Includes a tubing cutter, double flaring set
TF528D
increases the overall life of the clamp by
with a flaring bar, rod handle, yoke and (5)
not wearing down the teeth inside from
adaptors (3/16, 1/4, 5/16, 3/8 and 1/2ʺ) over the tube, greatly reducing the chance
repeated slipping
GENERAL
• Includes a storage case • Slender low-profile design allows the user
TF5A ‡ Double Flaring Tool Set to make flares on the vehicle in tight spaces
®
(Blue-Point ) • Flares can be achieved along the frame
• Makes double or single flares on soft rails or areas in the engine compartment,
steel, brass or aluminum tubing from saving the user time from having to remove
3/16–1/2ʺ O.D. components or complete lines to
• Makes a smooth fitting, crack-free 45° flare make repairs
• Set includes (5) adaptors, a yoke assembly, • Kit includes the constant tension
bar assembly and handle tubing cutter
TF5A • Storage case included TFL500 ‡ Flaring Kit (Blue-Point )
®
TFM5A ‡ Metric Double Flaring Tool Set • Used with a ratchet to make consistent
®
(Blue-Point ) flares faster and easier
• Same design as TF5A except for tubing with • Makes double flares on 3/16ʺ and
a O.D. from 4.75–10 mm 4.75 mm tubing
• Set includes a yoke, bar assembly, handle • Low-profile design allows for use on or off
and (5) adaptors (4.75, 5, 6, 8 and 10 mm) the car
TF275A Flaring and Swaging Set • Inline design makes a more accurate flare
®
(Blue-Point ) • Double clamp and hex screw design keeps
TF275A • 45° flare or swage soft copper, brass or tubing locked tightly in position
aluminum tubing • For use on thin-walled steel and
• Die blocks handle 1/8, 3/16, 1/4, 5/16, 3/8, copper tubing
®
7/16, 1/2, 5/8 and 3/4ʺ O.D. tubing TFL800 ‡ Flaring Kit (Blue-Point )
• Swages 3/16, 1/4, 5/16, 3/8, 1/2, 5/8 and • Used with a ratchet to make consistent
3/4ʺ O.D. tubing flares faster and easier
• Includes TF275PB Storage Case • Makes double flares on 3/16ʺ and
4.75 mm tubing
TFM428 Metric Bubble Flaring Set • Low-profile design allows for use on or
(Blue-Point ) off the car
®
• For automotive brake systems • Inline design makes a more accurate flare
• Designed for crack-free bubble flares on • Double clamp and hex screw design keeps
soft wall tubing up to a .028ʺ wall thickness tubing locked tightly in position
• Adaptors included for 4.75, 6, 8 and • For use on thin-walled steel and
10 mm flares copper tubing
• Includes TFM428PB storage case
®
TFM428 TFLM800 ‡ Flaring Kit (Blue-Point )
TFL20MK ‡ Master Inline Flaring Kit • Used with a ratchet to make consistent
®
(Blue-Point ) flares faster and easier
• Unique design locks the adaptors, cone, • Makes double flares on 4.75, 5, and
TFL500
and tube in a perfect line to help make 6 mm tubing
perfect factory flares every time • Low-profile design allows for use on the
car or off
• Inline design makes a more accurate flare
• Double clamp and hex screw design keeps
tubing locked tightly in position
TFL800 • For use on thin-walled steel and
copper tubing
434 TFLM800
