Page 304 - 实耐宝完整US版1500

OPEN END
WRENCHES

Four-Way Angle Head, mm
• Angle head wrenches are offset at 30° and 60°
angles to the handle
• Both ends are the same size to permit use of Set VSM814** VSM807B*
one wrench in four positions Contains:
SVSM807A*
Flank Drive Flank
®
Stock No. Plus B D E Drive
®
Stock No. Plus
10 VSM5210B SVSM10A 20 6 127 • • •
11 VSM5211B SVSM11A 22 6 137 • • •
12 VSM5212B SVSM12A 24 6 145 • • •
13 VSM5213B SVSM13A 26 6 154 • • •
14 VSM5214B SVSM14A 28 6 164 • • •
15 VSM5215B SVSM15A 30 7 173 • • •
16 VSM5216B SVSM16A 31 7 181 •
17 VSM5217B SVSM17A 34 7 191 • • •
18 VSM5218B SVSM18A 36 7 200 •
19 VSM5219B SVSM19A 37 7 210
VSM807B •
21 VSM5221B SVSM21A 41 8 228 •
22 VSM5222B SVSM22A 44 8 239 •
24 VSM5224B SVSM24A 47 8 254 •
27 VSM5227B SVSM27A 53 9 283 •
ASME B107.100 *Set includes storage tray.
®
**Set includes storage bag.

Four-Way Angle Head, inches Set VS828A** VS814A** VS807B* SVS807A*
Contains:
Flank Flank
®
Industrial Drive
®
Stock No. B D E Drive
Stock No. Plus Plus
Stock No.
1/4 VS8B — — 17/32 3/16 3-11/16 •
GVS24B 5/16 VS10B — — 21/32 3/16 4-1/4 •
11/32 VS11B — — 23/32 7/32 4-17/32 •
3/8 VS12B — SVS12A 25/32 7/32 4-27/32 • • • •
7/16 VS14B — SVS14A 7/8 7/32 5-13/32 • • • •
1/2 VS16B GVS16B SVS16A 1 1/4 5-31/32 • • • •
9/16 VS18B GVS18B SVS18A 1-1/8 1/4 6-9/16 • • • •
5/8 VS20B GVS20B SVS20A 1-1/4 9/32 7-1/8 • • • •
11/16 VS22B GVS22B SVS22A 1-3/8 9/32 7-11/16 • • • •
3/4 VS24B GVS24B SVS24A 1-15/32 9/32 8-9/32 • • • •
13/16 VS26B GVS26B SVS26A 1-19/32 5/16 8-27/32 • •
7/8 VS28B GVS28B SVS28A 1-23/32 5/16 9-13/32 • •
15/16 VS30B GVS30B SVS30A 1-27/32 11/32 10 • •
1 VS32B GVS32B SVS32A 1-31/32 11/32 10-9/16 • •
1-1/16 VS34B — SVS34A 2-3/32 11/32 11-1/8 • •
1-1/8 VS36B — SVS36A 2-3/16 3/8 11-23/32 • •
1-3/16 VS38B — SVS38A 2-11/32 3/8 12-9/32 •
VS807B
1-1/4 VS40B GVS40B SVS40A 2-7/16 13/32 12-7/8 • •
1-5/16 VS42B — — 2-9/16 13/32 13-7/16 •
1-3/8 VS44B — — 1-3/8 13/32 14 •
1-7/16 VS46B — — 2-27/32 7/16 14-19/32 •
1-1/2 VS48B — — 2-15/16 7/16 15-5/32 •
1-5/8 VS52B — — 3-7/32 15/32 16-5/16 •
1-11/16 VS54B — — 3-11/32 1/2 16-7/8 •
1-3/4 VS56B — — 3-15/32 1/2 17-7/16 •
1-13/16 VS58B — — 3-19/32 1/2 18 •
1-7/8 VS60B — — 3-23/32 17/32 18-19/32 •
2 VS64B — — 3-31/32 9/16 19-3/4 •
®
ASME B107.100 *Set includes storage tray.
**Set includes storage bag.
