FLANK DRIVE HIGH-PERFORMANCE OFFSET BOX
WRENCHES

Short Handle, 0° Offset, mm

A C E
8–10 XDHSFM810 12.1–14.9 6.2–7.6 162.9
10–12 XDHSFM1012 14.4–17.1 7.6–9.0 190.5
XDHSFM1214
12–14 XDHSFM1214 17.1–20.1 8.5–10.2 208.8
17–19 XDHSFM1719 23.8–26.3 11.3–12.1 260.3

Short Handle, 15° Offset, inches

A C E
XDHS1012 5/16–3/8 XDHS1012 31/64–9/16 1/4–5/16 7

Standard Handle, 15° Offset, mm Set XDHM606
Contains:
A C E
8–9 XDHM89 11.6–13.0 5.8–6.2 219.2 •
8–10 XDHM810 11.6–14.4 6.2–7.6 225.6
10–11 XDHM1011 14.4–15.6 7.6–8.5 246.3 •
10–12 XDHM1012 14.4–17.1 7.6–9.0 264.0
12–13 XDHM1213 17.1–18.7 9.0–9.0 277.6 •
12–14 XDHM1214 17.1–20.1 9.0–10.2 289.6
14–15 XDHM1415 20.1–21.5 9.8–10.9 313.1 •
14–17 XDHM1417 20.1–23.7 9.8–11.3 334.7
XDHM606 15–16 XDHM1516 21.5–22.6 10.9–10.9 334.8
17–19 XDHM1719 23.7–26.3 11.3–12.1 360.1 •
18–20 XDHM1820 24.9–27.3 12.1–13.6 384.0 •
Set includes storage tray.

Standard Handle, 15° Offset, inches Set XDH605
Contains:
A C E
7/32–1/4 XDH78A GXDH78A 11/32–3/8 13/64–15/64 7-15/64
1/4–5/16 XDH810B GXDH810B 3/8–29/64 1/4–1/4 8-3/64 •
5/16–3/8 XDH1012B GXDH1012B 29/64–35/64 1/4–19/64 8-7/8
3/8–7/16 XDH1214A GXDH1214A 35/64–5/8 19/64–11/32 9-11/16 •
7/16–1/2 XDH1416A — 11/32–3/4 11/32–23/64 10-7/16
1/2–9/16 XDH1618A GXDH1618A 23/32–13/16 23/64–13/32 11-7/16 •
9/16–5/8 XDH1820A — 13/16–29/32 13/32–7/16 12-3/8
XDH605 5/8–3/4 XDH2024A — 57/64–1-3/64 7/16–31/64 13-9/32 •
11/16–3/4 XDH2224A — 31/32–1-1/32 15/32–3/4 14-7/32
11/16–13/16 XDH2226A — 63/64–1-9/64 31/64–17/32 15-5/32 •
3/4–7/8 XDH2428 — 1-3/64–1-1/64 31/64–37/64 15-3/4
25/32–7/8 XDH2528 — 1-5/64–1-13/64 35/64–37/64 16-5/64
15/16–1 XDH3032 — 1-5/16–1-25/64 37/64–39/64 15-1/2
1-1/16–1-1/4 XDH3440 — 1-31/64–1-47/64 5/8–23/32 18-1/4
1-1/4–1-5/16 XDH4042 — 1-47/64–1-13/16 23/32–47/64 19-1/4
1-1/4–1-3/8 XDH4044 — 1-47/64–1-15/16 23/32–49/64 20-1/4
1-1/4–1-7/16 XDH4046 — 1-47/64–2 23/32–51/64 21
1-7/16–1-1/2 XDH4648 — 2–2-1/16 51/64–13/16 22
Aerospace Spec. AS954E Set includes storage tray.
