P. 298
®
FLANK DRIVE OFFSET BOX
WRENCHES
XB605A
XSM608A
Standard Handle, Short Handle,
10° Offset, inches Set XB605A 10° Offset, mm Set XSM608A
Contains: Contains:
A C E A C E
3/8–7/16 XB1214A 9/16–21/32 5/16–11/32 7-19/32 • 6–7 XSM67A 9.6–10.9 5.7–6.2 86 •
7/16–1/2 XB1416A 21/32–3/4 5/16–11/32 7-15/16 8–9 XSM89A 12.3–13.7 6.7–7.2 103 •
1/2–9/16 XB1618A 3/4–13/16 11/32–3/8 8-11/16 • 8–10 XSM810 12.3–15 6.7–7.7 107
9/16–5/8 XB1820A 13/16–29/32 13/32–7/16 9-13/32 9–10 XSM910A 13.7–15 7.2–7.7 112 •
5/8–11/16 XB2022A 29/32–1 7/16–15/32 10-5/32 • 11–12 XSM1112A 16.4–17.7 8.3–8.8 128 •
11/16–3/4 XB2224A 1–1-1/16 15/32–1/2 10-15/16 13–14 XSM1314A 19.1–20.4 9.3–9.8 146 •
3/4–13/16 XB2426A 1-1/16–1-5/32 1/2–17/32 11-21/32 • 15–16 XSM1516A 21.8–23.1 10.2–10.9 163 •
7/8–15/16 XB2830A 1-1/4–1-11/32 17/32–9/16 13-1/8 • 17–19 XSM1719A 24.5–27.2 11.4–12.3 185 •
15/16–1 XB3032A 1-11/32–1-13/32 9/16–19/32 13-7/8 18–20 XSM1820A 25.9–28.6 11.9–12.8 194 •
1–1-1/16 XB3234A 1-13/32–1-1/2 19/32–5/8 14-19/32 ASME B107.100 Set includes storage tray.
®
1-1/16–1-1/4 XB3440A 1-1/2–1-3/4 5/8–23/32 16-3/32
1-1/8–1-3/16 XB3638A 1-9/32–1-21/32 21/32–11/16 16-3/32
1-1/4–1-5/16 XB4042A 1-3/4–1-27/32 23/32–3/4 17-19/32
1-3/8–1-7/16 XB4446A 1-31/32–2-1/16 3/4–25/32 19-1/8
1-1/2–1-5/8 XB4852A 2-3/32–2-9/32 13/16–7/8 20-15/16
®
ASME B107.100 Set includes storage tray.
XID604KA
XS609A
Short Handle, 10° Offset, inches Set XS609A Midget, 10° Offset, inches Set XID604KA
Contains:
Contains:
A C E A C E
3/16–7/32 XS67A 5/16–11/32 7/32–7/32 3-27/32 • 3/16–13/64 XID1213A 5/16–11/32 1/8–5/32 2-13/16 •
1/4–5/16 XS810A 13/32–15/32 1/4–9/32 4-1/4 • 7/32–15/64 XID1415A 3/8–3/8 5/32–5/32 3-1/16 •
5/16–3/8 XS1012A 15/32–9/16 9/32–5/16 4-9/16 • 1/4–9/32 XID1618A 13/32–7/16 5/32–3/16 3-13/32 •
3/8–7/16 XS1214A 9/16–21/32 5/16–11/32 4-29/32 • 5/16–11/32 XID2022A 15/32–1/2 3/16–7/32 3-31/32 •
7/16–1/2 XS1416A 21/32–3/4 11/32–11/32 5-3/16 • ASME B107.100 Set includes storage bag.
®
1/2–9/16 XS1618A 3/4–13/16 3/8–3/8 5-17/32 •
9/16–5/8 XS1820A 13/16–29/32 13/32–7/16 5-7/8 •
5/8–3/4 XS2024A 29/32–1-1/16 7/16–1/2 6-3/8 •
11/16–13/16 XS2226A 1–1-5/32 15/32–17/32 6-23/32 •
ASME B107.100 Set includes storage tray.
®
