OPEN END

Aluminum (for AN fittings)
• Securely tighten expensive AN fittings to reduce risk of damage in aircraft,
marine and industrial applications, as well as race and show cars
• Machined from heat-treated aluminum to exacting tolerances
• Corner reliefs on open end prevent rounding the corners of the fitting
• Handle length is designed to apply appropriate torque without
overtightening
• Wrenches are color coded and stamped for quick size identification Set ANWR708A WRENCHES
• All wrenches are .36ʺ thick Contains:
Overall Length, inches
Stock No. Color
(mm)
No. 3 1/2 ANWR3A Silver 4 (101.6) •
No. 4 9/16 ANWR4A Black 4-3/4 (120.7) •
No. 6 11/16 ANWR6A Light Blue 5-3/4 (146.1) •
No. 8 7/8 ANWR8A Pink 5-3/4 (146.1) •
No. 10 1 ANWR10A Gold 7-1/8 (181.0) •
No. 12 1-1/4 ANWR12A Red 7-1/2 (190.5) •
No. 16 1-1/2 ANWR16A Brass 8-3/4 (222.3) •
No. 20 1-13/16 ANWR20A Dark Blue 9-1/4 (237.0) •
Set includes heavy-gauge vinyl storage pouch. ANWR708A

OPEN END (Blue-Point )
®

BDOEM1415 BDOE1820

®
®
Standard, mm (Blue-Point ) Standard, inches (Blue-Point )
Stock No. Length, mm Stock No. Length, inches
10–11 BDOEM1011 145 5/16–3/8 BDOE1012 5-5/16
12–13 BDOEM1213 165 7/16–1/2 BDOE1416 6-1/2
14–15 BDOEM1415 185 9/16–5/8 BDOE1820 7-9/32
16–17 BDOEM1617 185 11/16–3/4 BDOE2224 8-15/16
®
®
18–19 BDOEM1819 227 ASME /ANSI B107.100
FLANK DRIVE FLARE NUT
®

Open End and Flare Nut, mm Set RXSM605B
Contains:
A B C D E
8 RXSM8B 17 17 7 7 135
9 RXSM9B 18 19 7 7 144
10 RXSM10B 20 21 8 8 152 •
11 RXSM11B 21 23 9 9 162 •
12 RXSM12B 22 25 9 9 169 •
13 RXSM13B 24 27 9 9 178 •
14 RXSM14B 25 29 10 10 186 •
15 RXSM15B 26 31 10 10 194
16 RXSM16B 27 33 11 11 202
17 RXSM17B 29 35 11 11 211
18 RXSM18B 30 37 12 12 219 RXSM605B
19 RXSM19B 32 39 12 12 228
20 RXSM20B 33 41 13 13 235
®
ASME B107.100 Set includes storage tray.
303
• Use only moderate force on flare nut wrenches
• Do not use “cheater bars” on handles
• Read safety precautions on pages W1 to W4
