MarVision MM 420

Workshop Measuring Microscope with M3 Software

ACCESSORIES
Order no. Product name Product type

4246114 Optional DXF file integration for M3 software
4247027 Optional TV adapter, 0.67x (instead of 1.0x) 320 tv0.67
4247028 Optional Navitar zoom 6.5:1, motorized 320 zmo
4247029 Optional Navitar zoom 6.5:1, motorized with coaxial light 320 zmk
4247035 Optional Navitar 4 K Motor-Zoom 8x – 116x
4247050 Optional telecentric transmitted light for measuring rotationally symmetrical parts 200 ld
4247039 Optional telecentric transmitted light for Navitar 4 K motor-zoom 200 ldm
4245300 Optional coaxial LED incident light for zoom lens 320 kaz
4246050 Optional Z axis with measuring system 320 zm
4246051 Optional Z axis, extended by 200 mm 320 Zv
4246052 Optional Z axis, extended by 200 mm, including measuring system 320 zvm
4247020 Ancillary lens 0.5x (for Navitar objective lens only) 320 v0.5
4247021 Ancillary lens 0.75x (for Navitar objective lens only) 320 v0.75
4247022 Ancillary lens 1.5x (for Navitar objective lens only) 320 v1.5
4247023 Ancillary lens 2.0x (for Navitar objective lens only) 320 v2
4246801 Prisms, pair, for diameter 5– 55 mm (measuring tables 100x100 mm, 200x100 mm) 220 p
4246802 Center support, pair, center height 40 mm (measuring tables 100x100 mm, 200x100 mm) 220 sp
4246806 Center support, pivoting, pair, center height 50 mm, distance between centers 130 mm 220 sps
(measuring table 200 x 100 mm)
4246920 Pivoting glass plate, Ø 100 mm (measuring table 200 x 100 mm) 200 dk
4246821 90° stop for MM 220 / MM 320 220 as90
4246901 Calibration standard for circles, with calibration certificate 320 nkz
4246071 Protective cover for measuring tables 100x100 and 200x100 mm
4246115 Upgrade M3-Software Version V1 to V2
4246121 Upgrade M3 software from version V2 to V3
4246116 DXF option and profiling package for MM420
4246117 Upgrade from DXF to profiling for MM420 / MM420-CNC
4246118 Thread measuring option for MM420
4246119 Optional cable insulation measurement for MM420
4246831 Prisms, pair, for diameter 5– 55 mm (measuring table 250 x 170 mm) 220 p
4246833 Center support, pair, center height 40 mm (measuring table 250 x 170 mm) 220 sp
4246807 Center support, pivoting, pair, center height 50 mm, distance between centers 130 mm 220 sps
(measuring table 250 x 170 mm)
4246921 Pivoting glass plate, Ø 100 mm (measuring table 250 x 170 mm) 200 dg
4246072 Protective cover for measuring table 250x170 mm
4246054 Option measuring system for extended Z-axis (350 mm) 320 zvl
4246832 Prisms, pair, for diameter 5– 55 mm (measuring table 400 x 250 mm) 220 p
4246834 Center support, pair, center height 40 mm (measuring table 400 x 250 mm) 220 sp
4246808 Center support, pivoting, pair, center height 50 mm, distance between centers 130 mm 220 sps
(measuring table 400 x 250 mm)
4246922 Pivoting glass plate, Ø 100 mm (measuring table 400 x 250 mm) 200 db
4246825 90° stop for table 400x250 mm 220 as90– 1
4246073 Protective cover for measuring table 400x250 mm
