Precimar PLM-E

Precision Length Measuring Machine

DESCRIPTION

• The PLM-E precision length
measuring machine is an Abbe
compliant comparator mounted
on highly homogeneous rigid
granite in a horizontal
configuration
• Sensitive adjustment in 5 axes,
and object table with a loading
capacity of 35 kg
• PC-based, multi-axis machine
control, including PC workstation
and 828 WIN “Free measure-
ment” basic software
• Simple operating procedure by
means of measuring force-
adjusted and joystick-controlled
measuring slides with progres-
sive deflection characteristic and
automatic contact detection
• Automatic detection of outside TECHNICAL DATA
and inside measurements and
computer-aided search for
reversal points
• The motorized measuring slide Type PLM-E PLM-E
allows for high travel speeds Product name PLM 600-E PLM 1000-E
• The CNC-controlled vertical and Direct measuring range [mm] 200 200
cross adjustment of the universal
measuring table facilitates highly Measuring range for outer measure- 0 bis 600 0 to 1000
efficient measuring ment [mm]
• State-of-the-art machine control Measuring range for inner measure- 0.5 to 445 0.5 to 845
(MarEcon) ment [mm]
• Recording, processing, logging Measuring uncertainty MPE (L in ≤ (0.085 + L/1500) ≤ (0.085 + L/1500)
E1
mm) [µm]
and transfer of measurement Repeatability [µm] ≤ 0.05 ≤ 0.05
data via powerful software and
menu-driven controls Measuring forces [N] 0 to 13.9 0 to 13.9
• Software compensation of Device length [mm] 1660 2110
thermal dimensional deviations
• Very easy to set the measuring Mass [kg] 480 535
force using the software * Proof can be carried out at the Göttingen site if required
• Aerostatic guides for all slides
mounted on the machine bed
ensure low measurement uncer- APPLICATIONS ACCESSORIES
tainties
• Electronic generation of Calibration of: • Large number of accessory kits and modular
measuring force and automatic • Plain plug gages and gage rings components for completing a wide variety of
contacting • Setting gage rings measuring tasks, including the measurement of:
• Subjective influences largely • Snap gages • Thread gages
eliminated and unintended colli- • Spherical gage blocks, internal micrometers • Conical thread gages
sions with the test piece avoided. • Gage blocks • Gears
• Automatic bore and inner thread • Thread gages • Thread pitches
measurement • Taper thread gages
• Automatic TY adjustment: • Gear gages
What’s unique is that a manual • Dial indicators
TY-adjustment is still possible • Dial comparators
• Motorized tilting axis (TB) for • 2-point bore gages
alignment. Alignment is carried • Outside micrometers
out via the manual control panel • 2-point inside micrometers
or using the 828 WIN software. • Precision length measurement
• A factory calibration or DAkkS/ • Measurement of thin-walled and
DKD calibration is available for deformed
the Precimar PLM-E workpieces

For more information, please visit our website: www.mahr.com
