Page 343 - 蓝带金统立KINGTONY2025年样本

TORQUE CONTROL &
MULTIPLIERS
Electronic Torque Adapter

34607-1A

• Specifications: Memory
Accuracy ± 2% (+) Increase LED Peak & Trace
Memory 50 Power
Display Resolution 0.1 N‧m / ft‧lb , 0.01 kgf‧m LCD
Operation Mode Peak/Trace
Unit Selection kgf‧m, ft‧lb, N‧m Mem UNIT Peak
Battery AA x 2 PC.(Battery not included) kg-m Trace
N-m
Battery Life 110hrs (continuous operation) ft-lb
Operating Ambient -10 C - 60 C (13.9 F - 139.9 F)
°
°
°
°
Temperature
°
°
°
°
Storage Temperature -20 C - 70 C (-4 F - 157.9 F)
Operating Relative Humidity 15 to 90% noncondensing
Switch Off Automatically 70 seconds (if do not use LED
electronic torque adapter.)
LED Indicator Green. Red Battery Cap
Overload Alarm 1250 N‧m (922 ft‧lb)
(-) Decrease
• Dual Scale - Newton Meter & English & Kilogram-force meter ( N‧m / ft‧lb & kgf‧m)
KT NO. Square N‧m Torque range kgf‧m Size g
drive
mm
ft‧lb
34607-1A 3/4" 200 ~1000 N‧m 147.6~738 ft‧lb 20.4~102 kgf‧m L110 x W56 x H60 585 6 / 24
Torque Screwdriver
34211 34011
• Suitable for 1/4" Hex insert bit; 1/4" socket
• Automatic adjustment knob design
• Easy-to-read laser scale
• Ergonomic comfort rubber grip 34211
• Tolerance of torque ± 6%(CW)
• Quality meets DIN ISO 6789:2017 & ASME B107.300-2010
6 6.3 mm (1/4") hex Easy- to-read
5,000 driver for bit laser scale

34011

High quality Automatic
aluminum adjustment Ergonomic comfort
• Quick-Release
knob design rubber grip

KT NO. Spec. Torque range Incr. Overall length g
cN‧m / N‧m / in‧lb mm
34211-3DG 4~9 N‧m 0.1 N‧m 196 475 1 / 24
34011-1DG 30~120 cN‧m 1 cN‧m 180 207 1 / 24
34011-1EG 3~15 in‧lb 0.1 in‧lb 180 207 1 / 24
34011-2DG 1.5~6.5 N‧m 0.1 N‧m 196 475 1 / 24
34011-2EG 10~50 in‧lb 1.0 in‧lb 196 475 1 / 24
34011-3DG 0.5~2.5 N‧m 0.1 N‧m 180 207 1 / 24

302
