TORQUE CONTROL &
MULTIPLIERS
Electronic Torque Wrench

• Electronic torque value readout
• Peak and trace mode selection
• Buzzer and LED indicator for presetting target torque
• Engineering units (N‧m, ft‧lb, in‧lb, kgf‧m ) adjustment
• Switch off automatically after 60 seconds
• DIN ISO 6789:2017 & ASME B107.300-2010 Display :
LCD display (± 2 digit) with measuring
• CW ± 2% and CCW ± 2.5% operation ranges that can be selected for N‧m, ft‧lb,
in‧lb, kg‧m

Signal :
3-way signal when the maximum
LED warning light torque value is reached, as a result the
wrench can be used in noisy places.
Quick release

LCD
Battery Cap :
- AAAx3
- Battery life 110 hrs

• Electronic Torque Wrench
Preset
+ (Increase) LCD
LED Buzzer Battery Cap

34367-2DK
- (Decrease) 34467-2DK
(Clear)
Peak / Trace

Torque Accuracy CW ± 2% / CCW ± 2.5%
Preset Function 10
0.1 N‧m/ ft‧lb , 1.0 in‧lb,
Display Resolution
0.01 kgf‧m
Operation Mode Peak/Trace
Battery AAAx3 (Battery not included)
Backlight Yes (Nagative)
Alert LED & Buzzer
Operating Amblent -10°C ~ 60°C
Temperature
Storage Temperature -20°C ~ 70°C
Operation Relative Humidity 15 to 90% noncodensing

• Dual Scale - Newton Meter & English & Kilogram-force meter ( N‧m / in‧lb / ft‧lb & kgf‧m)

KT NO. Gear Square N.m in.lb Torque range ft.lb kgf.m Overall length g
teeth
drive
mm
34367-2AG 72 3/8" 27-135 N.m 239~1195 in.lb 19.9-99.6 ft.lb 2.75~13.76 kgf.m 460 1400 3 / 6
34467-1AG 36 1/2" 40-200 N.m 354~1770 in.lb 29.5-147.5 ft.lb 4.08~20.38 kgf.m 530 1500 3 / 6
