TORQUE CONTROL &
MULTIPLIERS
Adjustable Torque Wrench Set

344251A12MR 1/2"

• Blow case size (mm) : 12
• 500 x 125 x 70 (0.15cuft)
PC.
Contents Kg 2.85 1 / 10
34423-1A 42~210 N‧m
4335MR 13, 14, 15, 16, 17, 18, 19,
21, 22, 24
4251-04R
Heavy Duty Adjustable Aluminum Torque Wrench

• Industrial application
• Lightweight and robust housing made by aluminium alloy 10,000 3
• Multi-lever mechanism brings length independence and accurate torque
• Loud click sound and string impulse when torque value reached
• Easy lock and adjustment design
• Tolerance of torque ± 3%(CW)
• Quality accords to DIN ISO 6789:2017 & ASME B107.300-2010

Step: Pull out the Rocket-Arm,turn to 90º
and stress clockwise for adjusting the
1 requested torque value
90 °
Clear dual scale

2

°
90
Aluminium housing and ergonomically designed handgrip
L

3485G-2DB 750-2000Nm

3485G-2DB 750-2000Nm
Main Body A B C

1/2'' 3445G

Torque range

KT NO. Square N.m Incr. ft‧lb Incr. Main A B C Overall length kg
drive
mm
Body
3445G-1FB 1/2" 40~200 N.m 5 30~150 ft.lb 5 563 - - - 563 1.50 1 / 12
3/4'' 3465G

Torque range

KT NO. Square N.m Incr. ft‧lb Incr. Main A B C Overall length kg
drive
Body
mm
3465G-1FB 3/4" 110~550 N.m 10 80~400 ft.lb 10 827 - - - 827 3.00 1 / 2
3465G-2FB 3/4" 140~760 N.m 10 100~560 ft.lb 10 827 - - - 827 3.00 1 / 2
3465G-3FB 3/4" 200~1000 N.m 10 140~740 ft.lb 10 808 762 - - 1413 3.80 1 / 2
1'' 3485G

Torque range

KT NO. Square N.m Incr. ft‧lb Incr. Main A B C Overall length kg
drive
Body
mm
3485G-1DB 1" 600~1500 N.m 25 - - 945 - 771 362 1615 10.90 1 / 1
3485G-2DB 1" 750~2000 N.m 50 - - 947 - 945 924 2370 16.30 1 / 1
298
