Electronic Torque Adapter

34207-1A 34307-1A 34407-1A
• Specifications:
Accuracy ± 2%
Memory 50 LED
Display Resolution 0.1 N‧m /ft‧lb ,0.01 kgf‧m Peak & Trace LCD
Operation Mode Peak/Trace (-) Decrease
Unit Selection kgf‧m, ft‧lb, N‧m
Battery AAA x 2 PC.(Battery not included)
Battery Life 110hrs (continuous operation)
Operating Ambient -10 C - 60 C (13.9 F - 139.9 F)
°
°
°
°
Temperature
°
°
°
°
Storage Temperature -20 C - 70 C (-4 F - 157.9 F)
Operating Relative Humidity 15 to 90% noncondensing
70 seconds (if do not use
Switch Off Automatically
electronic torque adapter.)
LED Indicator Green. Red Battery Cap
34207-1A: 37.5 N‧m (27.6 ft‧lb) Memory (+) Increase
Overload Alarm 34307-1A: 168.8 N‧m(124.5 ft‧lb) Power
34407-1A: 250 N‧m (184.4 ft‧lb)

Dual Scale - Newton Meter & English & Kilogram-force meter ( N‧m / ft‧lb & kgf‧m)
KT NO. Square N‧m Torque range kgf‧m Size g
mm
drive
ft‧lb
34207-1A 1/4" 6~30 N‧m 4.4~22.1 ft‧lb 0.61~3.06 kgf‧m L75 x W45 x H40 124 12 / 48
34307-1A 3/8" 27~135 N‧m 19.9~99.6 ft‧lb 2.75~13.76 kgf‧m L75 x W45 x H40 198 12 / 48
34407-1A 1/2" 40~200 N‧m 29.5~147.5 ft‧lb 4.08~20.38 kgf‧m L75 x W45 x H40 199 12 / 48

34407T-1A

Peak & Trace
Accuracy ± 2% LCD LED
Memory 50
0.1 N‧m /ft‧lb ,0.01 kgf‧m (+) Increase
Display Resolution 1Psi /0.001 Bar /0.001 kgf‧cm² /0.01
Kpa
Operation Mode Peak/Trace
in‧lb, ft‧lb, Kgf‧m, Kgf‧cm, N‧m
Unit Selection
Kpa, Bar, psi, kgf‧cm²
Battery AAA x 2 PC.(Battery not included) (-) Decrease
Battery Life 50hrs (continuous operation)
Operating Ambient ° ° ° °
Temperature -10 C - 60 C (13.9 F - 139.9 F) Memory
°
°
°
°
Storage Temperature -20 C - 70 C (-4 F - 157.9 F) Battery Cap
Operating Relative Humidity 15 to 90% noncondensing Tire Pressure Gauge Power
Auto Shut Off 60 seconds

Dual Scale - Newton Meter & English & Kilogram-force meter ( N‧m / lbf‧ft & kgf‧m)

KT NO. Square N‧m Torque range kgf‧m Pressure range Size g
mm
drive
ft‧lb
1-100 psi
34407T-1A 1/2" 40-200 N‧m 29.5-147.5 ft‧lb 4.08~20.38 kgf‧m L75 x W67 x H46 mm 343 1 / 24
( 0.069~6.6bar )
301
