Impact Thin Wall Socket Impact Thin Wall Socket

KT No. & D1
4935S 1/2"
4930M 1/2"
• DIN 3121 • ANSI / ASME B107.2

D1 D2
D1 D2
l L
l L

ℓ
L
D2
D1
KT NO. inch mm mm mm mm g
D2
D1
ℓ
L
KT NO. mm mm mm mm mm g 493510S 5/16 13.0 25.0 12 80 129 6 / 120
493008M 8 13.2 25 12 78 118 6 / 120 493512S 3/8 16.0 25.0 12 80 144 6 / 120
493009M 9 14.0 25 12 78 118 6 / 120 493514S 7/16 16.7 25.0 13 80 148 6 / 120
493010M 10 15.5 25 12 80 134 6 / 120 493516S 1/2 19.0 25.0 14 80 159 6 / 120
493011M 11 16.7 25 13 80 136 6 / 120 493518S
493012M 12 18.0 25 14 80 142 6 / 120 9/16 20.5 25.0 14 80 165 6 / 120
493013M 13 19.0 25 14 80 165 6 / 120 493520S 5/8 23.0 25.0 16 80 167 6 / 96
493014M 14 20.5 25 14 80 153 6 / 120 493522S 11/16 24.5 30.0 17 80 235 6 / 96
493015M 15 21.5 30 16 80 204 6 / 96 493524S 3/4 27.0 30.0 18 80 224 6 / 96
493016M 16 23.0 30 16 80 219 6 / 96
493017M 17 24.5 30 16 80 218 6 / 96 493526S 13/16 29.0 30.0 20 80 250 6 / 96
493018M 18 25.5 30 17 80 267 6 / 96 493528S 7/8 30.5 30.0 22 80 260 5 / 60
493019M 19 27.0 30 18 80 241 6 / 96 493530S 15/16 33.0 30.0 24 80 336 5 / 60
493020M 20 28.0 30 20 80 235 6 / 96 493532S 1 34.0 30.0 24 80 356 5 / 60
493021M 21 29.0 30 20 80 241 6 / 96
493022M 22 30.5 30 22 80 252 5 / 60 493534S 1-1/16 37.0 30.0 27 80 405 5 / 60
493023M 23 32.0 30 24 80 267 5 / 60 493536S 1-1/8 39.0 30.5 27 80 355 5 / 50
493024M 24 33.0 30 24 80 277 5 / 60 493538S 1-3/16 40.5 30.0 30 80 417 5 / 50
493027M 27 37.0 30 27 80 318 5 / 60 493540S 1-1/4 42.5 30.0 32 80 389 5 / 50
493030M 30 40.5 30 30 80 355 5 / 50
493032M 32 42.5 30 32 80 356 5 / 50
493036M 36 45.5 30 36 80 361 1 / 24 Extra Thin Wall Impact
Socket

4935M 1/2"
• DIN 3121 4415M 1/2"
• Finishing - phosphate sunk
• For aluminum alloy wheel
D1 D2 • Material - chrome molybdenum alloy steel
• Super thin wall version has less strength than
l L a standard deep one
• DIN 3121
Thin walled design (D1)

ℓ
L
D1
D2
KT NO. mm mm mm mm mm g D1 l L D2
493510M 10 15.5 25 12 80 133 6 / 120
D1
D2
ℓ
L
493511M 11 16.7 25 13 80 134 6 / 120 KT NO. mm mm mm mm mm g
493512M 12 18.0 25 14 80 140 6 / 120 441517M 17 23.8 25 17 80 163 6 / 96
493513M 13 19.0 25 14 80 142 6 / 120 441519M 19 25.8 30 20 80 214 6 / 96
493514M 14 20.5 25 14 80 142 6 / 120 441521M 21 27.8 30 22 80 221 6 / 96
441522M 22 29.5 30 24 80 238 6 / 96
493516M 16 23.0 30 16 80 201 6 / 96
493517M 17 24.5 30 16 80 211 6 / 96 Wheel Nut Impact Socket
493519M 19 27.0 30 18 80 222 6 / 96
KT No. & D1
493521M 21 29.0 30 20 80 230 6 / 96 • Material - chrome molybdenum alloy steel
493522M 22 30.5 30 22 80 261 5 / 60 • Durable outer sleeve protects polished wheels and
493523M 23 32.0 30 24 80 273 5 / 60 lug nuts
493524M 24 33.0 30 24 80 285 5 / 60 • Plastic sleeve thin wall version
493526M 26 35.5 30 27 80 303 5 / 60
493527M 27 37.0 30 27 80 335 5 / 60
493530M 30 40.5 30 30 80 376 5 / 50
233
