IMPACT SOCKET &
ACCESSORIES
Impact Bit Socket KT No. & D1 Impact Accessory

1. Air pressure must not exceed 90PSI (6.3bar) & Set
2. Adjust your air tool to its lowest torque output,should this
torque level not be enough, increase it gradually 4269 1/2"
CAUTION
1740 409616M 1/2" • Torque extension bar
• Color coded and engraved with N‧m and lbf‧ft setting
• Hex bit & bit holder • Helps to eliminate overtorqued lug nut
• DIN 3121
4269-08-90
4269-08-A0
409616M 4269-08-B0
1740
4269-08-C0
30
L 4269-08-D5
S 16
L
16 4269-08-F0
L
S
KT NO. mm mm Max. torq g 4269-08-G0
N‧m
174010H H10 40 264.0 46 20 / 400 4269-08-H5
174012H H12 40 480.0 52 20 / 400 4269-08-J0
174014H H14 40 684.0 60 20 / 200
174017H H17 40 680.0 73 20 / 200 4269-08-K0
174019H H19 40 680.0 80 20 / 200
174022H H22 40 680.0 97 12 / 120 Torque(N.m)
409616M 16 38 680.0 145 10 / 160 250 Standard impact socket
Impact Accessory 200
150
90N.m Torque extension bar
4147 1/2" 100
50
• Bit holder Time(sec.)
• DIN 3121 0 1 2 3 4 5 1/2" Impact wrench
0.6Mpa Air pressure

KT NO. Size Overall length g
mm
414708S 1/4" 48 73 12 / 216
414710S 5/16" 48 79 12 / 216
414710M 10 mm 48 79 12 / 216
414A08S 1/2"

• Quick-release How to use torque extension bar
• Bit holder 1.Use with 1/2”DR. impact wrench, don’t use by hand.
2.Set air pressure 0.6 MPa(90 PSI) and adjust torque value between 190 N.m and 210 N.m.
• DIN 3121 3.Select suitable torque extension bar according to wheel nut size and indicated tightening torque.
4.Attach the torque extension bar with socket to impact wrench and apply load.
5.Check the actual tightening torque value by torque wrench.
6.Adjust air pressure or torque value according to the result of above.
7.Tight other wheel nuts in diagonal order.
Overall length
Max. torq
KT NO. Size Overall length g KT NO. Color N‧m lbf‧ft inch mm g
mm
414A08S 1/4" 50 93.6 10 / 180 4269-08-90 90 65 7-11/16 195 192
4269-08-A0 100 75 7-11/16 195 201
4260P 1/2" 4269-08-B0 110 80 7-11/16 195 217
90
• Extension bar 4269-08-C0 120 100 7-11/16 195 224
195
135
7-11/16
4269-08-D5
238
• DIN 3121 4269-08-F0 150 110 7-11/16 195 263
4269-08-G0 160 120 7-11/16 195 304
4269-08-H5 175 130 7-11/16 195 284
KT NO. Overall length g 4269-08-J0 190 140 7-11/16 195 331
inch mm
4260-03P 3 75 198 4 / 80 4269-08-K0 200 150 7-11/16 195 344
4260-04P 4 100 240 4 / 80
4260-05P 5 125 278 2 / 40
4260-06P 6 150 324 4 / 80
4260-08P 8 200 402 4 / 48
4260-10P 10 250 487 4 / 48
4260-12P 12 300 573 2 / 40
4260-16P 16 400 746 2 / 20
236
